3.34. LCE PC Board

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF

AG,AH,AJ,AM

AN,AP,AQ,AR

AS,AV,EE,YG

AE,AT,ED,YA

YB,YE,YF,YM

YN,YR,YS,YT

YU,YV,YX

AK AW YW AL YJ

C1 ECQE2105KF CAPACITOR, FILM 1µF, 250VDC - - - - - 1 1

C1 ECQE2474KF CAPACITOR, FILM 0.47µF, 250VDC 1 1 1 1 1 - -

C10 DZZZ999999 Not Mounted - 1 1 1 - - -

C10 ECQV1H105JL CAPACITOR, FILM 1µF, 50VDC 1 - - - - - 1

C10 ECQV1H155JL CAPACITOR, FILM 1.5µF, 50VDC - - - - 1 1 -

C11 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C12 ECQB1H683JF CAPACITOR, FILM 0.068µF, 50VDC - - - - - - 1

C12 ECQV1H683JL CAPACITOR, FILM 0.068µF, 50VDC 1 - - - - - -

C12 ECQB1H563JF CAPACITOR, FILM 0.056µF, 50VDC - - - 1 1 1 -

C12 DZZZ999999 Not Mounted - 1 1 - - - -

C13 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C14 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C15 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C16 DZZZ999999 Not Mounted 1 1 1 1 1 1 -

C16 ECQE2474KF CAPACITOR, FILM 0.47µF, 250VDC - - - - - - 1

C17 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C18 ECQB2472KF CAPACITOR, FILM 0.047µF, 200VDC 1 - - 1 1 1 1

C18 DZZZ999999 Not Mounted - 1 1 - - - -

C19 ECQB2472KF CAPACITOR, FILM 0.047µF, 200VDC 1 - - 1 1 1 1

C19 DZZZ999999 Not Mounted - 1 1 - - - -

C2 ECEA1HKA220 CAPACITOR, ELECTROLYTIC 22µF, 50VDC 1 1 1 1 1 1 1

C21 DZZZ999999 Not Mounted - 1 1 1 1 1 1

C21 ECQB1H473JF CAPACITOR, FILM 0.047µF, 50VDC 1 - - - - - -

C22 DZZZ999999 Not Mounted - 1 1 1 1 1 1

C22 ECQB1H473JF CAPACITOR, FILM 0.047µF, 50VDC 1 - - - - - -

C24 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C3 ECEA1CKA220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC 1 1 1 1 1 1 1

C4 ECEA1CN101U CAPACITOR, ELECTROLYTIC 100µF, 16VDC - 1 1 1 1 1 1

C4 ECEA1CN221U CAPACITOR, ELECTROLYTIC 220µF, 16VDC 1 - - - - - -

C5 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

C7 DZZZ999999 Not Mounted - 1 1 1 1 1 1

C8 ECEA1HKA3R3 CAPACITOR, ELECTROLYTIC 0.33µF, 50VDC - - - - - - 1

C8 ECQV1H225JL CAPACITOR, FILM 2.2µF, 50VDC 1 1 1 1 1 1 -

C9 ECQV1H225JL CAPACITOR, FILM 2.2µF, 50VDC - - - 1 - - -

C9 ECEA1HN220 CAPACITOR, ELECTROLYTIC 22µF, 50VDC 1 - - - 1 1 1

C9 ECQE2155KF CAPACITOR, FILM 1.5µF, 250VDC - 1 1 - - - -

CNJ20 DZFA000049 MODULAR CONNECTOR 1 1 1 1 1 1 1

or DZFA000062 MODULAR CONNECTOR 1 1 1 1 1 1 1

or DZFA000033 MODULAR CONNECTOR 1 1 1 1 1 1 1

CNJ21 DZFA000052 MODULAR CONNECTOR - 1 - - - - -

CNJ21 DZFA000061 MODULAR CONNECTOR 1 - - - 1 1 1

CNJ21 DZZZ999999 Not Mounted - - 1 1 - - -

or DZFA000032 MODULAR CONNECTOR 1 1 - - 1 1 1

or DZFA000052 MODULAR CONNECTOR 1 - - - 1 1 1

or DZFA000061 MODULAR CONNECTOR - 1 - - - - -

CNJ23 DZFA000049 MODULAR CONNECTOR - - 1 1 - - -

CNJ23 DZZZ999999 Not Mounted - - - - - 1 1

CNJ23 DZFA000052 MODULAR CONNECTOR 1 1 - - - - -

CNJ23 DZFA000061 MODULAR CONNECTOR - - - - 1 - -

or DZFA000062 MODULAR CONNECTOR - - 1 1 - - -

or DZFA000061 MODULAR CONNECTOR 1 1 - - - - -

or DZFA000052 MODULAR CONNECTOR - - - - 1 - -

or DZFA000033 MODULAR CONNECTOR - - 1 1 - - -

or DZFA000032 MODULAR CONNECTOR 1 1 - - 1 - -

CNJ24 DZZZ999999 Not Mounted 1 1 - - 1 1 1

CNJ24 DZFN000040 CONNECTOR, MODULAR - - 1 1 - - -

CNP22 DZZZ999999 Not Mounted 1 1 1 1 1 1 1

CNP25 DZFC000037 PH CONNECTOR 1 1 1 1 1 1 1

D1 DZAG000020 DIODE 1 1 1 1 1 1 1

or DZAG000055 DIODE 1 1 - - - - -

D10 DZAG000059 DIODE, ZENER 1 - - - - - -
