322
D10 DZFP000149 JUMPER 5mm - - 11111
D10 ERDS2TC0 RESISTOR - 1 -----
or DZAG000074 DIODE, ZENER 1 - -----
D11 ERDS2TC0 RESISTOR - 1 -----
D11 DZAG000059 DIODE, ZENER 1 - -----
D11 DZFP000149 JUMPER 5mm - - 11111
or DZAG000074 DIODE, ZENER 1 - -----
D12 DZAG000041 ZENER DIODE 1 1 11111
or DZAG000075 DIODE, ZENER 1 1 -----
D13 DZAG000041 ZENER DIODE 1 1 11111
or DZAG000075 DIODE, ZENER 1 1 -----
D14 DZZZ999999 Not Mounted 1 1 11111
D15 DZZZ999999 Not Mounted 1 1 11111
D16 DZAG000059 DIODE, ZENER 1 1 11111
or DZAG000074 DIODE, ZENER 1 1 -----
D17 DZAG000059 DIODE, ZENER 1 1 11111
or DZAG000074 DIODE, ZENER 1 1 -----
D19 DZZZ999999 Not Mounted 1 1 11111
D2 DZAG000020 DIODE 1 1 11111
or DZAG000055 DIODE 1 1 -----
D20 DZZZ999999 Not Mounted 1 1 11111
D21 DZZZ999999 Not Mounted 1 1 11111
D23 DZZZ999999 Not Mounted 1 1 11111
D24 DZZZ999999 Not Mounted 1 1 11111
D3 DZAG000020 DIODE - - 11--1
D3 DZZZ999999 Not Mounted 1 1 --11-
D4 DZAG000056 DIODE 1 1 11111
or DZAG000079 DIODE 1 1 -----
D5 DZAG000056 DIODE 1 1 11111
or DZAG000079 DIODE 1 1 -----
D6 DZAG000056 DIODE 1 1 11111
or DZAG000079 DIODE 1 1 -----
D7 DZAG000056 DIODE 1 1 11111
or DZAG000079 DIODE 1 1 -----
D8 DZAG000037 ZENER DIODE 1 1 11111
or DZAG000078 ZENER DIODE 1 1 -----
D9 DZAG000273 ZENER DIODE 1 - -----
D9 DZZZ999999 Not Mounted - 1 11111
IC1 DZAA000202 CURRENT DETECTOR IC 1 - ---11
IC1 DZZZ999999 Not Mounted - 1 111--
IC2 DZAA000930 NAND GATE 1 - ---11
IC2 DZZZ999999 Not Mounted - 1 111--
JP10 DZFP000149 JUMPER 5mm 1 - ----1
JP10 DZZZ999999 Not Mounted - 1 1111-
JP11 DZZZ999999 Not Mounted 1 1 11111
JP14 DZZZ999999 Not Mounted 1 1 11111
JP15 DZZZ999999 Not Mounted 1 1 11111
JP16 DZZZ999999 Not Mounted 1 1 11111
JP17 DZZZ999999 Not Mounted 1 1 11111
JP2 DZFP000149 JUMPER 5mm 1 1 --111
JP2 DZZZ999999 Not Mounted - - 11---
JP24 DZZZ999999 Not Mounted 1 1 11111
JP25 DZZZ999999 Not Mounted 1 1 11111
JP26 DZFP000149 JUMPER 5mm 1 1 11111
JP27 DZFP000149 JUMPER 5mm 1 1 11111
JP3 DZZZ999999 Not Mounted 1 1 111-1
JP3 DZFP000149 JUMPER 5mm - - ---1-
JP5 DZFP000149 JUMPER 5mm - - ---1-
JP5 DZZZ999999 Not Mounted 1 1 111-1
JP6 DZFP000149 JUMPER 5mm - - 11---
JP6 DZZZ999999 Not Mounted 1 1 --111
JP7 DZFP000149 JUMPER 5mm 1 - --1-1
JP7 DZZZ999999 Not Mounted - 1 11-1-
JP8 DZFP000149 JUMPER 5mm 1 - --1-1
Safety
Mark
Ref.
No.
Part Number Part Name Description
AA,AB,AD,AF
AG,AH,AJ,AM
AN,AP,AQ,AR
AS,AV,EE,YG
AE,AT,ED,YA
YB,YE,YF,YM
YN,YR,YS,YT
YU,YV,YX
AK AW YW AL YJ
To Next Page
