3.4. LPC PC Board (DP-2000/2500)
Safety
Mark
Ref. No. Part Number Part Name Description
C101 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C102 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C103 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C105 DZBA000187 CAPACITOR, CERAMIC 27pF, 50VDC
C106 DZBA000187 CAPACITOR, CERAMIC 27pF, 50VDC
C107 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C108 DZZZ999999 Not Mounted
C201 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C202 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C203 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C204 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C205 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C206 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C207 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C208 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C209 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C210 DZBA000222 CAPACITOR, CERAMIC 33pF, 50VDC
C305 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C307 DZBA000047 CAPACITOR, CERAMIC 1µF, 16VDC
C308 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C309 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C310 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C311 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C312 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C314 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C315 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C316 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C317 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C318 EEVHA1H100 CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C319 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C320 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C402 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C409 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C410 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C411 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C412 EEVHA1H100 CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C413 EEVHB1V220 CAPACITOR, ELECTROLYTIC 22µF, 35VDC
C415 EEVHB1C220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C417 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C418 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C419 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C501 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C502 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C503 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C505 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C506 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C507 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C508 DZBA000222 CAPACITOR, CERAMIC 33pF, 50VDC
C600 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C601 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C602 EEVHA1H100 CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C603 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C604 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C605 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C701 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C702 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C703 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C704 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C705 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C706 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C707 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C708 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C709 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
