Panasonic DP-3000 User Manual

266
3.8. ADF PC Board
Safety
Mark
Ref. No. Part Number Part Name Description
ARG1 DZFE000001 RAG TERMINAL RAGTERMINAL
C1 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C12 DZZZ999999 Not Mounted
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C15 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C17 DZZZ999999 Not Mounted
C18 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C19 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C2 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C21 DZZZ999999 Not Mounted
C22 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C25 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C26 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C27 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C28 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C29 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C3 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C32 EEAGA1V470 CAPACITOR, ELECTROLYTIC 47µF, 35VDC
C33 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C34 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C35 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C36 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C38 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C39 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C42 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C43 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C45 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C46 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C6 EEµFC1V151 CAPACITOR, ELECTROLYTIC 150µF, 35VDC
C8 DZZZ999999 Not Mounted
C9 DZZZ999999 Not Mounted
CA1 DZZZ999999 Not Mounted
CA2 DZZZ999999 Not Mounted
CA3 DZZZ999999 Not Mounted
CNP21 DZFC000594 CONNECTOR
CNP22 DZFC000012 PH CONNECTOR
CNP24 DZZZ999999 Not Mounted
CNP25 DZFC000041 PH CONNECTOR
CNP26 DZZZ999999 Not Mounted
CNP27 DZFC000017 PH CONNECTOR
CNP28 DZFC000029 PH CONNECTOR
CNP29 DZFC000052 PH CONNECTOR
CNP30 DZFC000058 PH CONNECTOR
CP1 DZDW000068 FUSE
CP2 DZDW000072 FUSE
CP3 DZZZ999999 Not Mounted
D1 DZAG000244 DIODE
D2 DZZZ999999 Not Mounted
D3 DZZZ999999 Not Mounted
D4 MA152A DIODE
IC1 DZAA001147 MOTOR DRIVER
IC4 DZZZ999999 Not Mounted
IC5 DZAF000046 TRANSISTOR ARRAY
NF1 DZDN000095 CHIP INDUCTOR
NF2 DZDN000095 CHIP INDUCTOR
NF3 DZZZ999999 Not Mounted
NF4 DZDN000095 CHIP INDUCTOR
NF5 DZDN000095 CHIP INDUCTOR
NF6 DZDN000095 CHIP INDUCTOR
