3.20. PNL3 PC Board
SW15 EVQ11L04M-1 TACT SWITCH
SW16 EVQ11L04M-1 TACT SWITCH
SW17 EVQ11L04M-1 TACT SWITCH
SW18 EVQ11L04M-1 TACT SWITCH
SW19 EVQ11L04M-1 TACT SWITCH
SW2 EVQ11L04M-1 TACT SWITCH
SW20 EVQ11L04M-1 TACT SWITCH
SW21 EVQ11L04M-1 TACT SWITCH
SW22 EVQ11L04M-1 TACT SWITCH
SW23 EVQ11L04M-1 TACT SWITCH
SW24 EVQ11L04M-1 TACT SWITCH
SW25 EVQ11L04M-1 TACT SWITCH
SW26 EVQ11Q04K TACT SWITCH
SW27 EVQ11L04M-1 TACT SWITCH
SW28 EVQ11L04M-1 TACT SWITCH
SW29 EVQ11L04M-1 TACT SWITCH
SW3 EVQ11L04M-1 TACT SWITCH
SW30 EVQ11L04M-1 TACT SWITCH
SW31 EVQ11L04M-1 TACT SWITCH
SW32 EVQ11Q04K TACT SWITCH
SW33 EVQ11Q04K TACT SWITCH
SW34 EVQ11L04M-1 TACT SWITCH
SW35 EVQ11L04M-1 TACT SWITCH
SW4 EVQ11L04M-1 TACT SWITCH
SW5 EVQ11L04M-1 TACT SWITCH
SW6 EVQ11L04M-1 TACT SWITCH
SW7 EVQ11L04M-1 TACT SWITCH
SW8 EVQ11L04M-1 TACT SWITCH
SW9 EVQ11L04M-1 TACT SWITCH
TL3 DZKP000150 PLATE, CONTACT A
TL4 DZKP000151 PLATE, CONTACT B
Safety
Mark
Ref. No. Part Number Part Name Description
CNJ70 DZFC000599 CONNECTORS
JW1 DZFP000149 JUMPER 5mm
JW2 DZFP000149 JUMPER 5mm
JW3 DZFP000149 JUMPER 5mm
LED1 LNJ876LKDEAB LED
LED2 LN376GCPX-2U LED
LED3 LN376GCPX-2U LED
LED4 LN376GCPX-2U LED
LED5 LN376GCPX-2U LED
LED6 LN376GCPX-2U LED
LED7 LN376GCPX-2U LED
LED8 LN376GCPX-2U LED
PCB DZEP000503 PC BOARD, PNL3
R1 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W
R10 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R11 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R12 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R2 DZZZ999999 Not Mounted
R3 ERDS2TJ682 RESISTOR, CARBON FILM 6.8KΩ, 1/4W
R4 DZZZ999999 Not Mounted
R5 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R6 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R7 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R8 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R9 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
RV1 DZBH000005 SLIDE POTENTIOMETER
SW1 EVQ11L04M-1 TACT SWITCH
SW2 EVQ11L04M-1 TACT SWITCH
Safety
Mark
Ref. No. Part Number Part Name Description
To Next Page
