3.19. PNL2 PC Board
Safety
Mark
Ref. No. Part Number Part Name Description
BZ1 DZDT000014 BUZZER
C1 ECBA1E223ZF5 CAPACITOR, CERAMIC 0.022µF, 25VDC
C2 DZZZ999999 Not Mounted
C3 DZZZ999999 Not Mounted
CNJ69 DZFC000432 CONNECTORS
or DZFC000590 CONNECTORS
D1 DZZZ999999 Not Mounted
JP5 DZFP000814 DOING LAMP HARNESS
JW1 DZFP000149 JUMPER 5mm
JW10 DZFP000149 JUMPER 5mm
JW11 DZFP000149 JUMPER 5mm
JW12 DZFP000149 JUMPER 5mm
JW13 DZFP000149 JUMPER 5mm
JW14 DZFP000149 JUMPER 5mm
JW15 DZFP000149 JUMPER 5mm
JW16 DZFP000149 JUMPER 5mm
JW17 DZFP000149 JUMPER 5mm
JW18 DZFP000149 JUMPER 5mm
JW19 DZFP000149 JUMPER 5mm
JW2 DZFP000149 JUMPER 5mm
JW20 DZFP000149 JUMPER 5mm
JW21 DZFP000149 JUMPER 5mm
JW22 DZFP000149 JUMPER 5mm
JW23 DZFP000149 JUMPER 5mm
JW24 DZFP000149 JUMPER 5mm
JW25 DZFP000149 JUMPER 5mm
JW26 DZFP000149 JUMPER 5mm
JW27 DZFP000149 JUMPER 5mm
JW28 DZFP000149 JUMPER 5mm
JW29 DZFP000149 JUMPER 5mm
JW3 DZZZ999999 Not Mounted
JW4 DZZZ999999 Not Mounted
JW9 DZFP000149 JUMPER 5mm
LED1 LNG301MPU LED
LED10 LN376GCPX-2U LED
LED11 LNJ876LKDEAB LED
LED12 LNJ876LKDEAB LED
LED2 LN376GCPX-2U LED
LED3 LNG301MPU LED
LED4 LN376GCPX-2U LED
LED5 LNJ876LKDEAB LED
LED6 LN376GCPX-2U LED
LED7 LNJ876LKDEAB LED
LED8 LN376GCPX-2U LED
LED9 LNJ876LKDEAB LED
PCB DZEP000470 PC BOARD, PNL2
Q1 DZAF000055 DIGITAL TRANSISTOR
Q2 DZAF000055 DIGITAL TRANSISTOR
Q3 DZAF000055 DIGITAL TRANSISTOR
R1 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R2 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R3 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R4 ERDS2TJ221 RESISTOR, CARBON FILM 220Ω, 1/4W
R5 ERG1SJ331 RESISTOR, METAL FILM 330Ω, 1W
R6 ERG1SJ331 RESISTOR, METAL FILM 330Ω, 1W
R7 ERG1SJ331 RESISTOR, METAL FILM 330Ω, 1W
R8 ERG1SJ331 RESISTOR, METAL FILM 330Ω, 1W
SW1 EVQ11L04M-1 TACT SWITCH
SW10 EVQ11L04M-1 TACT SWITCH
SW11 EVQ11L04M-1 TACT SWITCH
SW12 EVQ11L04M-1 TACT SWITCH
SW13 EVQ11L04M-1 TACT SWITCH
SW14 EVQ11L04M-1 TACT SWITCH
