290
3.22. PRIF PC Board
Safety
Mark
Ref. No. Part Number Part Name Description
C1 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C10 DZBA000204 CAPACITOR, CERAMIC 10pF, 50VDC
C11 DZBA000204 CAPACITOR, CERAMIC 10pF, 50VDC
C12 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C15 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C16 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C17 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C18 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C19 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C2 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C20 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C21 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C22 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C25 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C26 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C27 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C28 DZZZ999999 Not Mounted
C29 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C3 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C30 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C31 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C4 DZBA000222 CAPACITOR, CERAMIC 33pF, 50VDC
C5 DZBA000222 CAPACITOR, CERAMIC 33pF, 50VDC
C6 DZZZ999999 Not Mounted
C7 DZZZ999999 Not Mounted
C8 DZZZ999999 Not Mounted
C9 DZZZ999999 Not Mounted
CNJ211 DZFC000259 CONNECTOR
or DZFC000378 CONNECTOR
CNJ212 DZFC000319 CONNECTOR
or DZFC000580 CONNECTOR
CNP220 DZFC000228 CONNECTOR
D1 DZZZ999999 Not Mounted
IC1 DZAA000703 VHCMOS
IC2 DZAA001020 VHCMOS
IC3 DZAA000114 RESETTING IC
IC4 DZAA000093 INVERTER
IC5 DZAC000236 GATE ARRAY
IC6 DZAA001097 IEEE1284 TRANSCEIVER
IC7 DZAA000649 AND GATE
NF1 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF10 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF11 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF12 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF13 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF14 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF15 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF16 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF17 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF18 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF19 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF2 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF20 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF21 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF22 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF23 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF24 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF25 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF26 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
