319
3.33. LCU PC Board
Safety
Mark
Ref. No. Part Number Part Name Description AC, AU, YY
C1 ECQB1H222KF CAPACITOR, FILM 2200pF, 50VDC 1
C10 ECEA1VKA220 CAPACITOR, ELECTROLYTIC 22µF, 35VDC 1
C11 DZZZ999999 Not Mounted 1
C12 ERDS2TC0 RESISTOR 1
C2 ECQE2223KF CAPACITOR, FILM 0.022µF, 250VDC 1
C3 ECQE2334KF CAPACITOR, FILM 0.33µF, 250VDC 1
C4 ECEA1CN470U CAPACITOR, ELECTROLYTIC 47µF, 16VDC 1
C5 DZZZ999999 Not Mounted 1
C6 DZZZ999999 Not Mounted 1
C8 ECQE2474KF CAPACITOR, FILM 0.47µF, 250VDC 1
C9 ECEA1CKA220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC 1
CNJ20 DZFA000052 MODULAR CONNECTOR 1
or DZFA000061 MODULAR CONNECTOR 1
CNJ21 DZFA000052 MODULAR CONNECTOR 1
or DZFA000061 MODULAR CONNECTOR 1
CNJ23 DZFA000052 MODULAR CONNECTOR 1
or DZFA000061 MODULAR CONNECTOR 1
CNP22 DZZZ999999 Not Mounted 1
CNP25 DZFC000072 PH CONNECTOR 1
D1 DZAG000041 ZENER DIODE 1
or MA4062 ZENER DIODE 1
or DZAG000075 ZENER DIODE 1
D2 DZAG000041 ZENER DIODE 1
or MA4062 ZENER DIODE 1
or DZAG000075 ZENER DIODE 1
D3 DZAG000024 DIODE 1
D4 DZAG000024 DIODE 1
D5 DZAG000024 DIODE 1
D6 DZZZ999999 Not Mounted 1
D7 DZZZ999999 Not Mounted 1
F1 DZDW000011 FUSE 1
JP1 DZFP000149 JUMPER 5mm 1
JP10 DZFP000149 JUMPER 5mm 1
JP13 DZZZ999999 Not Mounted 1
JP14 DZZZ999999 Not Mounted 1
JP15 DZFP000149 JUMPER 5mm 1
JP2 DZFP000149 JUMPER 5mm 1
JP20 DZFP000149 JUMPER 5mm 1
JP21 DZFP000149 JUMPER 5mm 1
JP22 DZFP000149 JUMPER 5mm 1
JP23 DZFP000149 JUMPER 5mm 1
JP24 DZFP000149 JUMPER 5mm 1
JP25 DZFP000149 JUMPER 5mm 1
JP26 DZFP000149 JUMPER 5mm 1
JP27 DZFP000149 JUMPER 5mm 1
JP28 DZFP000149 JUMPER 5mm 1
JP29 DZFP000149 JUMPER 5mm 1
JP3 DZZZ999999 Not Mounted 1
JP30 DZFP000149 JUMPER 5mm 1
JP31 DZFP000149 JUMPER 5mm 1
JP32 DZFP000149 JUMPER 5mm 1
JP33 DZFP000149 JUMPER 5mm 1
JP34 DZFP000149 JUMPER 5mm 1
JP35 DZFP000149 JUMPER 5mm 1
JP36 DZFP000149 JUMPER 5mm 1
JP37 DZZZ999999 Not Mounted 1
JP38 DZZZ999999 Not Mounted 1
JP39 DZZZ999999 Not Mounted 1
JP4 DZZZ999999 Not Mounted 1
JP40 DZZZ999999 Not Mounted 1
JP41 DZFP000149 JUMPER 5mm 1
JP42 DZFP000149 JUMPER 5mm 1
JP43 DZFP000149 JUMPER 5mm 1
To Next Page
