330
3.39. RLB PC Board
3.40. FRM PC Board
Safety
Mark
Ref. No. Part Number Part Name Description AC, AE, AU, YY Others
ARG1 DZFE000001 RAG TERMINAL RAG TERMINAL 1 1
CNP171 DZFC000658 VA CONNECTOR 1 1
CNP172 DZFC000579 VA CONNECTOR 1 1
CNP173 DZFC000579 VA CONNECTOR 1 1
CNP175 DZFC000140 PH CONNECTOR 1 1
D1 DZAG000024 DIODE 1 1
F1 DZDW000080 FUSE 1 1
F2 DZFP000149 JUMPER 5mm 1 1
FH1 DZFH000002 FUSE CLIP 1 1
FH2 DZFH000002 FUSE CLIP 1 1
JW1 DZZZ999999 Not Mounted - 1
JW1 DZFP000149 JUMPER 5mm 1 -
JW2 DZZZ999999 Not Mounted 1 1
PCB DZEP000515 PC BOARD, RLB 1 1
RL1 DZZZ999999 Not Mounted 1 -
RL1 ADE304 MECHANICAL RELAY - 1
RL2 ADE304 MECHANICAL RELAY 1 1
SW1 AJ7220B POWER SWITCH 1 1
VA1 DZBM000015 ARRESTOR 1 -
VA1 DZZZ999999 Not Mounted - 1
VA2 DZBM000020 SURGE ABSORBER 1 -
VA2 DZZZ999999 Not Mounted - 1
VA3 DZBM000033 VARISTOR 1 -
VA3 DZBM000046 VARISTOR - 1
or DZBM000046 VARISTOR 1 -
Safety
Mark
Ref. No. Part Numver Part Name Description
C1 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C2 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C3 DZZZ999999 Not Mounted
C4 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC
CNJ1 DZFC000328 CONNECTOR
IC1 DZAA000770 FLASH MEMORY
PCB DZEP000334 PC BOARD, FRM
C3 DZZZ999999 Not Mounted
To Next Page
