3.7. SORT PC Board
Safety
Mark
Ref. No. Part Number Part Name Description
C1 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C12 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C15 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C16 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C17 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C18 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C19 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C2 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C20 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C21 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C22 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C25 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C26 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C27 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C28 DZBA000295 CAPACITOR, CERAMIC 10µF, 6.3VDC
C29 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C3 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C30 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C31 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C32 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C33 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C34 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C35 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C36 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C37 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C4 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C45 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C46 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C47 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C5 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C55 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC
C57 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C6 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C8 DZBA000295 CAPACITOR, CERAMIC 10µF, 6.3VDC
C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
CNP150 DZFC000543 CONNECTOR
CNP151 DZFA000093 DIMM SOCKET
IC1 DZAA000095 TRIPLE INVERTER
IC2 DZAA001056 CODEC
IC3 DZAC000233 GATE ARREY
IC4 DZAA001101 SD-RAM
or DZAA001337 SD-RAM
or DZAA001338 SD-RAM
or DZAA001339 SD-RAM
JP5 DZDN000135 CHIP INDUCTOR
JP7 DZDN000135 CHIP INDUCTOR
NF1 DZDN000010 CHIP INDUCTOR
NF2 DZDN000095 CHIP INDUCTOR
NF3 DZDN000095 CHIP INDUCTOR
PCB DZEP000502 PC BOARD, SORT
R1 ERJ3GEYJ105B RESISTOR, CHIP 1MΩ, 1/16W
R10 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R11 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R12 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R13 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W
R14 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W
