3.32. LANC PC Board
R68 DZZZ999999 Not Mounted 1
R69 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R7 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1
R70 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R71 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R72 DZZZ999999 Not Mounted 1
R73 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R74 ERJ6GEY0R00B RESISTOR, CHIP 0Ω, 1/10W 1
R75 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R76 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R77 DZZZ999999 Not Mounted 1
R78 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R79 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R8 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R80 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R81 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R82 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R83 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R84 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R85 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1
R86 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R87 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R88 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R89 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R9 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R90 DZZZ999999 Not Mounted 1
R91 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1
R92 DZZZ999999 Not Mounted 1
R93 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R94 DZZZ999999 Not Mounted 1
R95 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R96 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1
R97 DZZZ999999 Not Mounted 1
R98 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
R99 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1
SW1 DZZZ999999 Not Mounted 1
T1 DZDG000053 SINGLE 10/100BASE-TX
TRANSFORMER CMC MODULE
1
T1 DZDG000058 SINGLE 10/100BASE-TX
TRANSFORMER CMC MODULE
1
TP1 DZFE000001 RAG TERMINAL RAGTERMINAL 1
TP2 DZFE000001 RAG TERMINAL RAGTERMINAL 1
TP3 DZZZ999999 Not Mounted 1
TP4 DZZZ999999 Not Mounted 1
X1 DZDP000121 CRYSTAL UNIT 1
PCB DZEP000497 PC BOARD, LANB 1
Safety
Mark
Ref. No. Part Number Part Name Description
AB, AC, AF, AG, AK, AL
AQ, AU, AV, EE, YW, YX
CNJ201 DZFA000082 MODULAR CONNECTOR 1
CNP200 DZFC000056 CONNECTOR 1
LED1 DZAG000239 LED 1
LED2 DZAG000239 LED 1
R1 ERDS2TJ271 RESISTOR, CARBON FILM 270Ω, 1/4W 1
R2 ERDS2TJ271 RESISTOR, CARBON FILM 270Ω, 1/4W 1
TP1 DZFE000001 RAG TERMINAL RAG TERMINAL 1
PCB DZEP000446 PC BOARD, LANC 1
Safety
Mark
Ref. No. Part Number Part Name Description
AB, AC, AF, AG, AK, AL
AQ, AU, AV, EE, YW, YX
