3.12. CST2 PC Board (DP-3000)
Safety
Mark
Ref. No. Part Number Part Name Description
C1 EEAGA1C100B CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C2 EEAGA1H100B CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C3 ECBT1H471KB5 CAPACITOR 470µF, 50VDC
C4 ECBT1H471KB5 CAPACITOR 470µF, 51VDC
C5 ECBT1H471KB5 CAPACITOR 470µF, 52VDC
C6 ECBT1H471KB5 CAPACITOR 470µF, 53VDC
C7 ECBT1H471KB5 CAPACITOR 470µF, 54VDC
CNP770 DZFC000695 CONNECTOR
CNP771 DZFC000653 CONNECTOR
CNP772 DZFC000650 CONNECTOR
CNP773 DZFC000101 CONNECTOR
CNP774 DZFC000548 CONNECTOR
CNP775 DZFC000052 CONNECTOR
CNP776 DZFC000017 CONNECTOR
CNP777 DZFC000047 CONNECTOR
CNP778 DZFC000016 CONNECTOR
CP1 DZDW000145 FUSE
D1 DZAG000508 DIODE
D2 DZAG000508 DIODE
D3 DZAG000508 DIODE
JW1 DZFP000149 JUMPER
JW2 DZFP000149 JUMPER
JW3 DZFP000149 JUMPER
JW4 DZFP000149 JUMPER
JW5 DZFP000149 JUMPER
JW6 DZFP000149 JUMPER
JW7 DZFP000149 JUMPER
NF1 DZDN000009 FERRITE BEADS INDUCTOR
NF2 DZDN000009 FERRITE BEADS INDUCTOR
NF3 DZDN000009 FERRITE BEADS INDUCTOR
PCB DZEP000589 PC Board, CST2
Q1 2SD893A TRANSISTOR
Q2 2SD893A TRANSISTOR
Q3 DZAF000197 TRANSISTOR
R1 ERDS2TJ332T RESISTOR, CARBON FILM 3.3kΩ, 1/4W
R10 ERDS2TJ331T RESISTOR, CARBON FILM 330Ω, 1/4W
R11 ERDS2TJ331T RESISTOR, CARBON FILM 330Ω, 1/4W
R12 DZZZ999999 Not Mounted
R14 DZFP000149 JUMPER
R15 DZFP000149 JUMPER
R16 DZFP000149 JUMPER
R17 DZFP000149 JUMPER
R18 DZFP000149 JUMPER
R2 ERDS2TJ473T RESISTOR, CARBON FILM 47kΩ, 1/4W
R3 ERDS2TJ332T RESISTOR, CARBON FILM 3.3kΩ, 1/4W
R4 ERDS2TJ473T RESISTOR, CARBON FILM 47kΩ, 1/4W
R5 ERDS2TJ152T RESISTOR, CARBON FILM 1.5kΩ, 1/4W
R6 ERDS2TJ473T RESISTOR, CARBON FILM 47kΩ, 1/4W
R7 ERDS2TJ331T RESISTOR, CARBON FILM 330Ω, 1/4W
R8 ERDS2TJ331T RESISTOR, CARBON FILM 330Ω, 1/4W
R9 ERDS2TJ331T RESISTOR, CARBON FILM 330Ω, 1/4W
