3.42. MAIN LVPS PC Board (200V)
R7 ERDS1TJ183 RESISTOR, CARBON FILM 18KΩ, 1/2W
R8 ERX12SJ6R8 RESISTOR, METAL FILM 6.8Ω, 1/2W
R9 ERX12SJ6R8 RESISTOR, METAL FILM 6.8Ω, 1/2W
RF1 DZBQ000009 THERMAL CUTOFF WITH RESISTER
RF2 DZBQ000009 THERMAL CUTOFF WITH RESISTER
T1 ETB42AE165 TRANSFORMER
T2 ETB16BZ135 TRANSFORMER
VR1 EVMEASA01B52 VARIABLE REGISTOR
VR2 EVMEASA01B13 VARIABLE REGISTOR
Z1 ERZV14D241 VARISTOR
Z2 ERZV14D751 VARISTOR
Z3 ERZV14D182 VARISTOR
ZD1 DZAG000443 ZENER D
ZD101 MA4062N ZENER D
ZD102 MA4270N ZENER D
ZD103 MA4051N ZENER D
ZD2 MA4047N ZENER D
ZD302 MA4051N ZENER D
Safety
Mark
Ref. No. Part Number Part Name Description
C1 ECQU2A105ML CAPACITOR, FILM 1µF, 275VDC
C101 EVQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C102 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C103 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C104 EEUFC1V561 CAPACITOR, ELECTROLYTIC 560µF, 35VDC
C105 ECQB1H682JF CAPACITOR, FILM 6800pF, 50VDC
C106 ECQB1H682JF CAPACITOR, FILM 6800pF, 50VDC
C107 EEUFC1V102 CAPACITOR, ELECTROLYTIC 1000pF, 35VDC
C108 ECQB1H471JF CAPACITOR, FILM 470pF, 50VDC
C109 EEUFC1V102 CAPACITOR, ELECTROLYTIC 1000pF, 35VDC
C11 ERCKR1H101KB5 CAPACITOR, CERAMIC 100pF, 50VDC
C110 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C111 HRR2R102K CAPACITOR, CERAMIC 1000pF, 250VDC
C112 EEUFC1V390 CAPACITOR, ELECTROLYTIC 39µF, 35VDC
C113 ECQB1H102JF CAPACITOR, FILM 1000pF, 50VDC
C114 EEUFC1A472 CAPACITOR, ELECTROLYTIC 4700PF, 10VDC
C115 EEFUC1H180 CAPACITOR, ELECTROLYTIC 18pF, 50VDC
C116 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C117 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C118 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C119 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C12 ECA1HHG4R7 CAPACITOR, ELECTROLYTIC 4.7µF, 50VDC
C13 ECA1H104JL CAPACITOR, ELECTROLYTIC 0.1µF, 50VDC
C14 DZBA000496 CAPACITOR, CERAMIC
C15 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C16 EEUFZ1V220 CAPACITOR, ELECTROLYTIC 22µF, 35VDC
C17 DZBA00496 CAPACITOR, CERAMIC
C18 EEUFC1H180 CAPACITOR, ELECTROLYTIC 18µF, 50VDC
C19 DZBA00496 CAPACITOR, CERAMIC
C2 DZBA000285 CAPACITOR, CERAMIC 1000pF, 250VDC
C20 DZBA000496 CAPACITOR, CERAMIC
Safety
Mark
Ref. No. Part Number Part Name Description
