3.15. EXFD PC Board
R94 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
R95 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
R96 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
X1 DZDP000336 CRYSTAL UNIT
XIC3 DZFA000044 IC SOCKET
Safety
Mark
Ref. No. Part Number Part Name Description
C10 ECJ2XB1H104K CAPACITOR, CERAMIC 0.1µ F, 50VDC
C13 ECJ1XB1C104K CAPACITOR, CERAMIC 0.1µ F, 16VDC
C14 EEVHA1A101 CAPACITOR, ELECTROLYTIC 100µF, 10VDC
C15 EEVHA1A101 CAPACITOR, ELECTROLYTIC 100µF, 10VDC
C16 EEVHA1H220 CAPACITOR, ELECTROLYTIC 22µF, 50VDC
C17 EEVHA1H220 CAPACITOR, ELECTROLYTIC 22µF, 50VDC
C2 ECJ1XB1H222K CAPACITOR, CERAMIC 2200pF, 50VDC
C3 ECJ1XB1H222K CAPACITOR, CERAMIC 2200pF, 50VDC
C4 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C5 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C7 ECJ2XB1H104K CAPACITOR, CERAMIC 0.1µF, 50VDC
C8 ECJ2XB1H104K CAPACITOR, CERAMIC 0.1µF, 50VDC
C9 ECJ2XB1H104K CAPACITOR, CERAMIC 0.1µF, 50VDC
CNP790 DZFC000570 CONNECTOR
CNP791 DZFC000052 PH CONNECTOR
CNP792 DZFC000017 PH CONNECTOR
CNP793 DZFC000051 PH CONNECTOR
CNP794 DZFC000058 PH CONNECTOR
D1 DZAG000244 DIODE
D2 DZAH000013 DIODE
D3 DZAH000013 DIODE
D4 MA152A DIODE
D5 MA152A DIODE
IC1 DZAA000890 STEPPER MOTOR DRIVER IC
ICP1 DZDW000031 FUSE
PCB DZEP000488 PC BOARD, EXFD
Q1 DZAF000042 TRANSISTOR
Q2 DZAF000042 TRANSISTOR
Q3 DZAF000042 TRANSISTOR
Q4 DZAF000031 NPN SILICON TRANSISTOR
Q5 DZAF000031 NPN SILICON TRANSISTOR
R10 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R13 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R14 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R15 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R16 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R17 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W
R18 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W
R19 ERJ6GEYJ331B RESISTOR, CHIP 330Ω, 1/10w
R20 ERJ6GEYJ331B RESISTOR, CHIP 330Ω, 1/10w
R21 ERJ6GEYJ331B RESISTOR, CHIP 330Ω, 1/10w
R22 ERJ6GEYJ331B RESISTOR, CHIP 330Ω, 1/10w
R23 ERJ6GEYJ331B RESISTOR, CHIP 330Ω, 1/10w
R24 ERJ3GEYJ272B RESISTOR, CHIP 2.7KΩ, 1/16W
R26 ERJ3GEYJ151B RESISTOR, CHIP 150Ω, 1/16W
R27 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R28 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R29 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R3 ERX1SJ1R0 RESISTOR, METAL FILM 1Ω, 1W
R30 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R31 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R4 ERX1SJ1R0 RESISTOR, METAL FILM 1Ω, 1W
R5 ERJ3GEYJ222B RESISTOR, CHIP 2.2KΩ, 1/16W
R6 ERJ3GEYJ222B RESISTOR, CHIP 2.2KΩ, 1/16W
Safety
Mark
RefNo Part Number Part Name Description
