338
3.43. OPTION LVPS PC Board (100V)
Safety
Mark
Ref. No. Part Number Part Name Description
C1 ECQU2A224ML CAPACITOR, FILM 0.22µF, 275VDC
C10 ECQE6223RKF CAPACITOR, FILM 0.022µF, 630VDC
C101 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C102 EEUFC1V391 CAPACITOR, ELECTROLYTIC 390µF, 35VDC
C103 ECQB1H223JF CAPACITOR, FILM 0.022µF, 50VDC
C104 EEUFC1V391 CAPACITOR, ELECTROLYTIC 390µF, 35VDC
C105 ECQB1H272JF CAPACITOR, FILM 2700pF, 50VDC
C106 EEUFC1V820 CAPACITOR, ELECTROLYTIC 82µF, 35VDC
C107 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C11 DZBA000495 CAPACITOR, CERAMIC 330pF, 1KVDC
C14 DZBA000495 CAPACITOR, CERAMIC 330pF, 1KVDC
C2 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
C3 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
C4 ECQU2A224ML CAPACITOR, FILM 0.22µF, 275VDC
C5 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
C6 EETHC2D391H CAPACITOR, ELECTROLYTIC 390µF, 200VDC
C7 EETHC2D391H CAPACITOR, ELECTROLYTIC 390µF, 200VDC
C8 ECQB1H822JF CAPACITOR, FILM 8200pF, 50VDC
C9 EEUFC1V270 CAPACITOR, ELECTROLYTIC 27µF, 35VDC
CN64 DZFC000114 CONNECTOR
CN65 DZFC000415 CONNECTOR
CN66 DZFC000014 CONNECTOR
D1 DZAH000008 DIODE
D101 DZAH000034 DIODE
D2 DZAG000033 DIODE
D3 MA700A DIODE
D4 DZAG000175 DIODE
D5 DZAG000027 DIODE
D6 DZAG000027 DIODE
F1 DZDW000110 FUSE
F2 DZDX000009 THERMAL CUTOFF
L1 ELF20N018A FILTER CHOKE
L2 EXCELDR35V BEAD INDUCTOR
L3 EXCELDR35V BEAD INDUCTOR
L4 ELF15N015A FILTER CHOKE
L5 JUMPER
L6 EXCELDR35V BEAD INDUCTOR
M1 ME33B1 MODULE
PC1 ON3171 OPTOISOLATOR
PC2 ON3171 OPTOISOLATOR
Q1 DZAF000133 FFT
Q101 2SB3311A TR
R1 ERDS1TJ474 RESISTOR, CARBON FILM 470KΩ, 1/2W
R10 ERDS1TJ681 RESISTOR, CARBON FILM 680KΩ, 1/2W
R101 ERG2SJ120 RESISTOR, METAL FILM 12Ω, 2W
R102 ERDS2TJ183 RESISTOR, CARBON FILM 18kΩ, 1/4W
R103 ERDS2TJ101 RESISTOR, CARBON FILM 100Ω, 1/4W
R104 ERDS2TJ182 RESISTOR, CARBON FILM 1.8KΩ, 1/4W
R105 ERDS2TJ562 RESISTOR, CARBON FILM 5.6kΩ, 1/4W
R106 ERG2SJ102 RESISTOR, METAL FILM 1KΩ, 2W
R107 ERDS2TJ471 RESISTOR, CARBON FILM 470Ω, 1/4W
To Next Page
