305
3.30. G3B PC Board
R81 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R82 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R83 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R84 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R85 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R86 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R87 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R88 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R89 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R9 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R90 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R91 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R92 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R93 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R94 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R95 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R96 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R97 DZZZ999999 Not Mounted
R98 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
Safety
Mark
Ref.
No.
Part Number Part Name Description
AA,AB,AD,AF,AG,AH
AJ,AM,AN,AP,AQ,AR
AS,AV,EE,YG,YJ,YW
AE,AT,ED,YA,YB
YE,YF,YM,YN,YR
YS,YT,YU,YV,YX
AK
AL
AW
AC
AU
YY
C1 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C100 DZZZ999999 Not Mounted 1 1 1 1
C101 DZZZ999999 Not Mounted 1 1 1 1
C102 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC 1 1 1 1
C103 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C104 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C105 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C106 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C107 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C11 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C110 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C111 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C112 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C119 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC 1 1 1 1
C12 DZBA000209 CAPACITOR, CERAMIC 22pF, 50VDC 1 1 1 1
C120 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC 1 1 1 1
C121 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC 1 1 1 1
C122 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC 1 1 1 1
C123 DZZZ999999 Not Mounted 1 1 1 1
C124 DZZZ999999 Not Mounted 1 1 1 1
C125 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC 1 1 1 1
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C134 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1
C135 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1
C14 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C140 DZZZ999999 Not Mounted 1 1 1 1
C141 DZZZ999999 Not Mounted 1 1 1 1
C15 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C152 DZZZ999999 Not Mounted 1 1 1 1
C153 EEVHA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC 1 1 1 1
C154 EEVHA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC 1 1 1 1
C155 DZZZ999999 Not Mounted 1 1 1 1
C156 DZBA000231 CAPACITOR, CERAMIC 1200pF, 50VDC 1 1 1 1
C157 DZBA000211 CAPACITOR, CERAMIC 0.22µF, 16VDC 1 1 1 1
C158 DZBA000211 CAPACITOR, CERAMIC 0.22µF, 16VDC 1 1 1 1
C159 DZBA000211 CAPACITOR, CERAMIC 0.22µF, 16VDC 1 1 1 1
C16 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1
C160 DZZZ999999 Not Mounted 1 1 1 1
Safety
Mark
Ref. No. Part Number Part Name Description
