3.18. PNL1 PC Board
Safety
Mark
Ref. No. Part Number Part Name Description
C1 DZZZ999999 Not Mounted
C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C12 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C15 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C16 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C17 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C18 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C19 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C2 DZZZ999999 Not Mounted
C20 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C21 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C22 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C25 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C26 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C27 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C28 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C29 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C3 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C30 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C31 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C32 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C33 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C34 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C35 EEVHA1C220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C36 EEVHA1V100 CAPACITOR, ELECTROLYTIC 10µF, 35VDC
C37 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C38 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C39 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC
C4 DZBA000187 CAPACITOR, CERAMIC 27pF, 50VDC
C40 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC
C41 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC
C42 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC
C43 DZBA000197 CAPACITOR, CERAMIC 0.047µF, 25VDC
C44 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C45 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C46 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C47 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C49 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C50 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C51 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C52 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C53 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C54 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C55 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C56 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C57 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C58 EEVHA1V220 CAPACITOR, ELECTROLYTIC 22µF, 35VDC
C59 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C6 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C60 EEVHA1C220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C61 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C62 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C63 EEVHA1C220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C64 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C65 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C66 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C67 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C68 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
