Panasonic DP-3000 User Manual

280
C69 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC
C7 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C70 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C71 DZBA000221 CAPACITOR, CERAMIC 18pF, 50VDC
C72 DZBA000209 CAPACITOR, CERAMIC 22pF, 50VDC
C73 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C74 EEVHA1C220 CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C75 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C76 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C77 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C78 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C79 EEVHA1V100 CAPACITOR, ELECTROLYTIC 10µF, 35VDC
C8 DZBA000209 CAPACITOR, CERAMIC 22pF, 50VDC
C80 DZZZ999999 Not Mounted
C81 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C82 DZZZ999999 Not Mounted
C83 DZZZ999999 Not Mounted
C84 EEVHA1V100 CAPACITOR, ELECTROLYTIC 10µF, 35VDC
C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
CNJ61 DZFC000559 CONNECTOR
CNJ63 DZFC000557 CONNECTOR
CNJ66 DZFC000262 CONNECTORS
or DZFC000601 CONNECTOR
CNJ67 DZFC000274 CONNECTORS
or DZFC000600 CONNECTOR
CNP60 DZZZ999999 Not Mounted
CNP62 DZFC000410 CONNECTOR
CNP64 DZFC000323 CONNECTOR
CNP65 DZFC000038 PH CONNECTOR
CNP68 DZFC000598 PIN CONNECTOR
D1 DZAF000036 DIODE
D2 DZAG000070 DIODE
D3 DZAF000036 DIODE
D4 DZAG000070 DIODE
D5 MA748 Diodes
D6 MA704 DIODE
D7 MA704 DIODE
IC1 DZZZ999999 Not Mounted
IC10 DZAA000088 D FLIP FLOP
IC11 DZAA001060 FLASH MEMORY
or DZAA001091 FLASH MEMORY
IC12 DZAA000777 SRAM
IC13 DZAA000777 SRAM
IC14 DZAA000114 RESETTING IC
IC15 DZAA000352 RTC
IC17 DZZZ999999 Not Mounted
IC2 DZAC000217 MASK CPU7041SH
IC3 DZAA000081 INVERTER
IC4 DZAA000088 D FLIP FLOP
IC5 DZAA000086 OR GATE
IC6 DZAA000402 HCMOS
IC7 DZAA000882 LCD CONTROLLER
IC8 DZAA000295 AND GATE
IC9 DZAA001065 TOUCH PANEL CONTROLLER
JP1 DZZZ999999 Not Mounted
NF1 DZDL000002 FILTER, TIP EMI Filter, tip, EMI
NF10 DZDN000103 CHIP EMIFIL
NF11 DZDN000103 CHIP EMIFIL
NF12 DZDN000103 CHIP EMIFIL
NF13 DZDN000103 CHIP EMIFIL
NF14 DZDN000103 CHIP EMIFIL
NF15 DZDN000103 CHIP EMIFIL
NF16 DZDN000103 CHIP EMIFIL
NF17 DZDN000103 CHIP EMIFIL
NF18 DZDN000103 CHIP EMIFIL
NF19 DZDN000103 CHIP EMIFIL
Safety
Mark
Ref. No. Part Number Part Name Description
