Panasonic DP-3000 User Manual

339
3.44. OPTION LVPS PC Board (200V)
R108 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R109 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R11 JUMPER
R110 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R111 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W
R12 ERG1SJ180 RESISTOR, METAL FILM 18Ω, 1/2W
R13 ERX12SJ5R6 RESISTOR, METAL FILM 5.6Ω, 1/2W
R14 ERDS2TJ273 RESISTOR, CARBON FILM 27KΩ, 1/4W
R15 ERG1SJ333 RESISTOR, METAL FILM 33KΩ, 2W
R17 ERG1SJ333 RESISTOR, METAL FILM 33KΩ, 2W
R18 ERDS2TJ823 RESISTOR, CARBON FILM 82KΩ, 1/4W
R19 MPC2WR15KS RESISTOR, METAL PLATE 0.15Ω, 2W
R2 ERDS2TJ683 RESISTOR, CARBON FILM 68KΩ, 1/4W
R20 JUMPER
R21 ERG2SJ100 RESISTOR, METAL FILM 10Ω, 2W
R22 ERG1SJW100 RESISTOR, METAL FILM 10Ω, 1W
R23 OPEN
R3 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
R4 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
R5 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
R6 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
R7 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
R8 ERDS1TJ223 RESISTOR, CARBON FILM 22KΩ, 1/2W
T1 ETB35BC1W8 TRANSFORMER
TF1 DZBL000005 THERMISTOR
TH2 DZBL000005 THERMISTOR
Z1 ERZVGAD241 VARISTOR
Z2 ERZVGAD471 VARISTOR
ZD1 MA4220N ZENER D
ZD101 MA4062N ZENER D
ZD2 MA4300N ZENER D
Safety
Mark
Ref. No. Part Number Part Name Description
C1 ECQU2A224ML CAPACITOR, FILM 0.22µF, 275VDC
C10 ECQE6223RKF CAPACITOR, FILM 0.022µF, 630VDC
C101 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C102 EEUFC1V391 CAPACITOR, ELECTROLYTIC 390µF, 35VDC
C103 ECQB1H223JF CAPACITOR, FILM 0.022µF, 50VDC
C104 EEUFC1V391 CAPACITOR, ELECTROLYTIC 390µF, 35VDC
C105 ECQB1H272JF CAPACITOR, FILM 2700pF, 50VDC
C106 EEUFC1V820 CAPACITOR, ELECTROLYTIC 82µF, 35VDC
C107 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C11 DZBA000495 CAPACITOR, CERAMIC 330pF, 1KVDC
C14 DZBA000495 CAPACITOR, CERAMIC 330pF, 1KVDC
C2 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
C3 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
C4 ECQU2A224ML CAPACITOR, FILM 0.22µF, 275VDC
C5 DZBA000182 CAPACITOR, CERAMIC 2200pF, 250VDC
Safety
Mark
Ref. No. Part Number Part Name Description
