312

3.31. LANB PC Board

R75 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R76 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R77 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W - - 1 -

R77 ERJ3GEYJ273B RESISTOR, CHIP 27KΩ, 1/16W 1 1 - 1

R78 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R79 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R8 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W 1 1 1 1

R80 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R81 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R82 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R83 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R84 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R85 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R86 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R87 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R88 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R89 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R9 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R90 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R91 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R92 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R93 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R94 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R95 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R96 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R97 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R98 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R99 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

TP1 DZFE000001 RAG TERMINAL RAG TERMINAL 1 1 1 1

TP2 DZFE000001 RAG TERMINAL RAG TERMINAL 1 1 1 1

X1 DZDP000121 CRYSTAL UNIT 1 1 1 1

Safety

Mark

Ref. No. Part Number Part Name Description

AB, AC, AF, AG, AK, AL

AQ, AU, AV, EE, YW, YX

C1 DZZZ999999 Not Mounted 1

C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C100 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C101 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C102 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C103 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C104 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C105 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C106 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C107 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C108 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C109 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C11 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C110 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C111 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C112 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C113 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C114 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C115 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C116 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C117 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C118 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC 1

C119 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC 1

C12 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C120 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC 1

C121 DZBA000192 CAPACITOR, CERAMIC 0.01µF, 50VDC 1

C122 DZZZ999999 Not Mounted 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG,AH

AJ,AM,AN,AP,AQ,AR

AS,AV,EE,YG,YJ,YW

AE,AT,ED,YA,YB

YE,YF,YM,YN,YR

YS,YT,YU,YV,YX
