3.9. iADF PC Board
PCB DZEP000473 PC BOARD, ADF
Q1 DZAF000008 NPN SILICON TRANSISTOR
R1 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R11 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R15 DZZZ999999 Not Mounted
R16 DZZZ999999 Not Mounted
R19 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R2 ERJ3GEYJ561B RESISTOR, CHIP 560Ω, 1/16W
R21 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R22 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R23 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R24 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R25 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R26 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R27 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R28 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R29 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R3 ERX3SJR22 RESISTOR, METAL FILM 0.22Ω, 3W
R30 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R31 DZZZ999999 Not Mounted
R32 DZZZ999999 Not Mounted
R33 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R34 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R35 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R36 DZZZ999999 Not Mounted
R39 ERJ6GEY0R00B RESISTOR, CHIP 0Ω, 1/10W
R4 ERX3SJR22 RESISTOR, METAL FILM 0.22Ω, 3W
R40 ERJ6GEY0R00B RESISTOR, CHIP 0Ω, 1/10W
R43 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R5 DZZZ999999 Not Mounted
R51 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R52 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
RA1 EXBV8V102J CHIP RESISTOR ARRAY 1KΩ, 1/16W
RA2 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA3 EXBV8V102J CHIP RESISTOR ARRAY 1KΩ, 1/16W
RA4 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA5 EXBV8V102J CHIP RESISTOR ARRAY 1KΩ, 1/16W
RA6 DZZZ999999 Not Mounted
Safety
Mark
Ref. No. Part Number Part Name Description
ARG1 DZFE000001 RAG TERMINAL RAG TERMINAL
C1 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C12 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C15 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C17 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C18 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C19 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C2 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C21 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C22 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C25 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C26 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C27 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C28 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C29 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C3 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
Safety
Mark
Ref. No. Part Number Part Name Description
