268
C32 EEAGA1V470 CAPACITOR, ELECTROLYTIC 47µF, 35VDC
C33 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C34 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C35 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C36 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C38 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C39 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C42 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C43 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C45 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C46 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C6 EEUFC1V151 CAPACITOR, ELECTROLYTIC 150µF, 35VDC
C8 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
C9 EEUGA1C470 CAPACITOR, ELECTROLYTIC 47µF, 16VDC
CA1 DZZZ999999 Not Mounted
CA2 DZZZ999999 Not Mounted
CA3 DZZZ999999 Not Mounted
CNP21 DZFC000594 CONNECTOR
CNP22 DZFC000012 PH CONNECTOR
CNP24 DZFC000014 PH CONNECTOR
CNP25 DZFC000041 PH CONNECTOR
CNP26 DZFC000054 PH CONNECTOR
CNP27 DZFC000017 PH CONNECTOR
CNP28 DZFC000029 PH connector
CNP29 DZFC000052 PH CONNECTOR
CNP30 DZFC000058 PH CONNECTOR
CP1 DZDW000068 FUSE
CP2 DZDW000072 FUSE
CP3 DZDW000072 FUSE
D1 DZAG000244 DIODE
D2 MA152A DIODE
D3 MA152A DIODE
D4 MA152A DIODE
IC1 DZAA001147 MOTOR DRIVER
IC4 DZAF000046 TRANSISTOR ARRAY
IC5 DZAF000046 TRANSISTOR ARRAY
NF1 DZDN000095 CHIP INDUCTOR
NF2 DZDN000095 CHIP INDUCTOR
NF3 DZDN000095 CHIP INDUCTOR
NF4 DZDN000095 CHIP INDUCTOR
NF5 DZDN000095 CHIP INDUCTOR
NF6 DZDN000095 CHIP INDUCTOR
PCB DZEP000473 PC BOARD, ADF
Q1 DZAF000008 NPN SILICON TRANSISTOR
R1 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R11 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R15 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R16 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R19 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R2 ERJ3GEYJ561B RESISTOR, CHIP 560Ω, 1/16W
R21 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R22 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R23 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R24 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R25 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R26 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R27 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R28 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R29 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R3 ERX3SJR22 RESISTOR, METAL FILM 0.22Ω, 3W
R30 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R31 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R32 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R33 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R34 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R35 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
Safety
Mark
Ref. No. Part Number Part Name Description
