3.11. CST2 PC Board (DP-2000/2500)
Safety
Mark
Ref. No. Part Number Part Name Description
C1 EEAGA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C2 EEAGA1H100 CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C3 ECBA1H471KB5 CAPACITOR, CERAMIC 470pF, 50VDC
C4 ECBA1H471KB5 CAPACITOR, CERAMIC 470pF, 50VDC
C5 ECBA1H471KB5 CAPACITOR, CERAMIC 470pF, 50VDC
C6 ECBA1H471KB5 CAPACITOR, CERAMIC 470pF, 50VDC
C7 ECBA1H471KB5 CAPACITOR, CERAMIC 470pF, 50VDC
CNP770 DZFC000654 CONNECTOR
CNP771 DZFC000650 CONNECTOR
CNP772 DZFC000653 CONNECTOR
CNP773 DZFC000101 PH CONNECTOR
CNP774 DZFC000548 CONNECTOR
CNP775 DZFC000052 PH CONNECTOR
CNP776 DZFC000017 PH CONNECTOR
CNP777 DZFC000047 PH CONNECTOR
CNP778 DZFC000016 PH CONNECTOR
D1 DZAG000056 DIODE
D2 DZAG000056 DIODE
D3 DZAG000056 DIODE
ICP1 DZDW000071 FUSE
JW1 DZFP000149 JUMPER 5mm
JW2 DZFP000149 JUMPER 5mm
JW3 DZFP000149 JUMPER 5mm
JW4 DZFP000149 JUMPER 5mm
JW5 DZFP000149 JUMPER 5mm
JW6 DZFP000149 JUMPER 5mm
JW7 DZFP000149 JUMPER 5mm
NF1 DZDN000009 FERRITE BEADS INDUCTOR
NF2 DZDN000009 FERRITE BEADS INDUCTOR
NF3 DZDN000009 FERRITE BEADS INDUCTOR
PCB DZEP000489 PC BOARD, CST2
Q1 2SD893A TRANSISTOR
Q2 2SD893A TRANSISTOR
Q3 DZAF000197 TRANSISTOR
R1 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W
R10 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W
R11 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W
R12 DZZZ999999 Not Mounted
R14 DZFP000149 JUMPER 5mm
R15 DZFP000149 JUMPER 5mm
R16 DZFP000149 JUMPER 5mm
R17 DZFP000149 JUMPER 5mm
R18 DZFP000149 JUMPER 5mm
R2 ERDS2TJ473 RESISTOR, CARBON FILM 47KΩ, 1/4W
R3 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W
R4 ERDS2TJ473 RESISTOR, CARBON FILM 47KΩ, 1/4W
R5 ERDS2TJ152 RESISTOR, CARBON FILM 1.5KΩ, 1/4W
R6 ERDS2TJ473 RESISTOR, CARBON FILM 47KΩ, 1/4W
R7 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W
R8 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W
R9 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W
