Panasonic DP-3000

331
3.41. MAIN LVPS PC Board (100V)
Safety
Mark
Ref. No. Part Number Part Name Description
C1 ECQU2A105ML CAPACITOR, FILM 1µF, 275VDC
C101 EVQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C102 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C103 DZBA000494 CAPACITOR, CERAMIC 470pF, 500VDC
C104 EEUFC1V561 CAPACITOR, ELECTROLYTIC 560µF, 35VDC
C105 ECQB1H682JF CAPACITOR, FILM 6800pF, 50VDC
C106 ECQB1H682JF CAPACITOR, FILM 6800pF, 50VDC
C107 EEUFC1V102 CAPACITOR, ELECTROLYTIC 1000pF, 35VDC
C108 ECQB1H471JF CAPACITOR, FILM 470pF, 50VDC
C109 EEUFC1V102 CAPACITOR, ELECTROLYTIC 1000pF, 35VDC
C11 ERCKR1H101KB5 CAPACITOR, CERAMIC 100pF, 50VDC
C110 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C111 HRR2R102K CAPACITOR, CERAMIC 1000pF, 250VDC
C112 EEUFC1V390 CAPACITOR, ELECTROLYTIC 39µF, 35VDC
C113 ECQB1H102JF CAPACITOR, FILM 1000pF, 50VDC
C114 EEUFC1A472 CAPACITOR, ELECTROLYTIC 4700PF, 10VDC
C115 EEFUC1H180 CAPACITOR, ELECTROLYTIC 18pF, 50VDC
C116 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C117 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C118 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C119 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C12 ECA1HHG4R7 CAPACITOR, ELECTROLYTIC 4.7µF, 50VDC
C13 ECA1H104JL CAPACITOR, ELECTROLYTIC 0.1µF, 50VDC
C14 DZBA000496 CAPACITOR, CERAMIC 220pF, 2KVDC
C15 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C16 EEUFZ1V220 CAPACITOR, ELECTROLYTIC 22µF, 35VDC
C17 DZBA000496 CAPACITOR, CERAMIC 220pF, 2KVDC
C18 EEUFC1H180 CAPACITOR, ELECTROLYTIC 18µF, 50VDC
C19 DZBA000496 CAPACITOR, CERAMIC 220pF, 2KVDC
C2 DZBA000285 CAPACITOR, CERAMIC 1000pF, 250VDC
C20 DZBA000496 CAPACITOR, CERAMIC 220pF, 2KVDC
C201 ECQE6103RKF CAPACITOR, FILM 0.01µF, 630V
C202 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C203 ECQB1H102JF CAPACITOR, FILM 1000pF, 50VDC
C204 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C3 DZBA000285 CAPACITOR, CERAMIC 1000pF, 250VDC
C301 EEUFC1E152 CAPACITOR, ELECTROLYTIC 1500µF, 25VDC
C303 ECQV1H104JL CAPACITOR, FILM 0.1µF, 50VDC
C4 DZBA000285 CAPACITOR, CERAMIC 1000pF, 250VDC
C5 DZBA000285 CAPACITOR, CERAMIC 1000pF, 250VDC
C6 ECQU2A474ML CAPACITOR, FILM 0.47µF, 275VDC
C7 ECQB1H103JF CAPACITOR, FILM 0.01µF, 50VDC
C8 EETHC2D122K CAPACITOR, ELECTROLYTIC 1200µF, 200VDC
C9 EETHC2D122K CAPACITOR, ELECTROLYTIC 1200µF, 200VDC
CN60 DZFC000114 CONNECTOR
CN61 DZFC000013 CONNECTOR
CN62 DZFC000584 CONNECTOR
CN63 DZFC000014 CONNECTOR
CR1 DZAJ000001 TRIAC
CR201 DZAJ000008 THYRYSTOR
D1 DZAG000441 DIODE
D101 DZAG000442 DIODE
D102 DZAG000442 DIODE
