325
3.35. SRU PC Board
R5 ERDS2TJ122 RESISTOR, CARBON FILM 1.2KΩ, 1/4W - - - - - - 1
R6 ERDS2TJ620 RESISTOR, CARBON FILM 62Ω, 1/4W - - 1 1 - - -
R6 DZZZ999999 Not Mounted 1 1 - - 1 1 1
R7 DZZZ999999 Not Mounted 1 1 - - 1 1 1
R7 ERDS2TJ150 RESISTOR, CARBON FILM 15Ω, 1/4W - - 1 1 - - -
R8 DZZZ999999 Not Mounted 1 1 1 1 1 1 1
R9 DZZZ999999 Not Mounted 1 1 1 1 1 1 1
RL1 DZCK000010 RELAY - 1 - - 1 - -
RL1 DZZZ999999 Not Mounted 1 - 1 1 - 1 1
RL2 DZCK000007 RELAY 1 - 1 1 1 1 1
RL2 DZCK000007 RELAY - 1 - - - - -
or ATXD20428 RELAY 1 1 1 1 1 1 1
RL3 DZZZ999999 Not Mounted 1 1 - - 1 1 -
RL3 DZCK000008 RELAY - - 1 1 - - 1
RL4 DZCK000026 PHOTO RELAY 1 1 1 1 1 1 1
or DZCK000019 PHOTO RELAY - - - 1 1 1 1
SA1 DZJC000059 SOCKET ANGLE - - 1 1 - - -
T1 DZDE000008 LINE TRANSFORMER 1 - - 1 1 1 1
T1 DZDE000006 TRANSFORMER - 1 1 - - - -
T2 DZZZ999999 Not Mounted 1 1 1 1 1 1 1
TB1 DZFE000001 RAG TERMINAL RAGTERMINAL 1 1 1 1 1 1 1
VA1 DZBM000009 SURGE ABSORBER 1 - - - - - 1
VA1 DZZZ999999 Not Mounted - 1 1 1 1 1 -
VA2 DZBM000014 SURGE ABSORBER - 1 1 1 1 1 1
VA2 DZBM000024 SURGE ABSORBER 1 - - - - - -
VA3 DZBM000014 SURGE ABSORBER - 1 1 1 1 1 1
VA3 DZBM000024 SURGE ABSORBER 1 - - - - - -
VA4 DZBM000021 METAL OXIDE VARISTOR 1 1 1 1 1 1 1
or DZBM000012 METAL OXIDE VARISTOR 1 1 1 1 1 1 1
VA5 DZZZ999999 Not Mounted - 1 1 1 1 1 1
Safety
Mark
Ref.
No.
Part Number Part Name Description
AU
AC
ED,YB,YE,YF
YM,YN,YR,YS
YU,YV,YX
YA
YT
YY
AE AK AT YW
PCB DZEP000498 PC Board, SRU 1 - - - - - -
PCB DZEP000027 PC Board, SRU - 1 1 1 1 1 1
BZ1 DZDT000003 PIEZOELECTRIC RINGER 1 1 1 1 1 1 1
C1 ECQE2105KF CAPACITOR, FILM 1µF, 250VDC 1 1 1 1 1 1 1
C10 ECQB1H472JF CAPACITOR, FILM 4700pF, 50VDC 1 - 1 - - 1 -
C11 ECQB1H223JF CAPACITOR, FILM 0.022µF, 50VDC 1 1 1 - 1 1 1
C11 ECQB1H273JF CAPACITOR, FILM 27000pF, 50VDC - - - 1 - - -
C12 ECQB1H223JF CAPACITOR, FILM 0.022µF, 50VDC 1 1 1 1 1 1 1
C13 ECQB1H103JF CAPACITOR, FILM 0.01µF, 50VDC - - 1 - - 1 -
C13 ECQB1H822JF CAPACITOR, FILM 8200pF, 50VDC - - - - 1 - -
C13 ECQB1H332JF CAPACITOR, FILM 3300pF, 50VDC - 1 - 1 - - 1
C13 ECQB1H153JF CAPACITOR, FILM 15000pF, 50VDC 1 - - - - - -
C14 ECQB1H223JF CAPACITOR, FILM 0.022µF, 50VDC - - 1 - - 1 -
C14 ECQB1H122JF CAPACITOR, FILM 1200pF, 50VDC - - - - - - 1
C14 ECQB1H152JF CAPACITOR, FILM 1500pF, 50VDC - 1 - 1 - - -
C14 ECQB1H273JF CAPACITOR, FILM 27000pF, 50VDC - - - - 1 - -
C14 ECQB1H472JF CAPACITOR, FILM 4700pF, 50VDC 1 - - - - - -
C15 ECQB1H562JF CAPACITOR, FILM 5600pF, 50VDC 1 - - - - - -
C15 ECQB1H332JF CAPACITOR, FILM 3300pF, 50VDC - - 1 - 1 1 -
C15 ECQB1H682JF CAPACITOR, FILM 6800pF, 50VDC - 1 - 1 - - -
C16 ECBA1H102KB5 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1 1 1 1
C17 ECQB1H333JF CAPACITOR, FILM 33000pF, 50VDC 1 1 1 1 1 1 1
Safety
Mark
Ref.
No.
Part Number Part Name Description
AA,AB,AD,AF
AG,AH,AJ,AM
AN,AP,AQ,AR
AS,AV,EE,YG
AE,AT,ED,YA
YB,YE,YF,YM
YN,YR,YS,YT
YU,YV,YX
AK AW YW AL YJ
