Panasonic DP-3000 User Manual

324
or DZFP000149 JUMPER 5mm 1 - -----
R11 DZZZ999999 Not Mounted 1 1 1111-
R11 DZFP000149 JUMPER 5mm - - ----1
R12 ERDS2TJ101 RESISTOR, CARBON FILM 100Ω, 1/4W - - 11---
R12 DZZZ999999 Not Mounted 1 1 --111
R13 DZZZ999999 Not Mounted - 1 11111
R13 EROS2CKF2000 RESISTOR, METAL FILM 200Ω, 1/4W 1 - -----
R14 ERG1SJ222 RESISTOR, METAL FILM 2.2KΩ, 1W 1 1 11111
R15 ERG1SJ122 RESISTOR, METAL FILM 1.2KΩ, 1W 1 1 11111
R16 DZZZ999999 Not Mounted - 1 11111
R18 ERDS2TJ912 RESISTOR, CARBON FILM 9.1KΩ, 1/4W 1 - -1---
R18 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W - - ---1-
R18 ERDS2TJ103 RESISTOR, CARBON FILM 10KΩ, 1/4W - 1 1-1-1
R19 ERDS2TJ242 RESISTOR, CARBON FILM 2.4KΩ, 1/4W 1 - -----
R19 ERDS2TJ272 RESISTOR, CARBON FILM 2.7KΩ, 1/4W - - -1---
R19 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W - - ----1
R19 ERDS2TJ392 RESISTOR, CARBON FILM 3.9KΩ, 1/4W - 1 1-1--
R19 ERDS2TJ682 RESISTOR, CARBON FILM 6.8KΩ, 1/4W - - ---1-
R2 ERDS2TJ393 RESISTOR, CARBON FILM 39KΩ, 1/4W - - ----1
R2 ERDS2TJ823 RESISTOR, CARBON FILM 82KΩ, 1/4W 1 - -----
R2 ERDS2TJ184 RESISTOR, CARBON FILM 180KΩ, 1/4W - - ---1-
R2 ERDS2TJ683 RESISTOR, CARBON FILM 68KΩ, 1/4W - 1 111--
R20 ERG1SJ180 RESISTOR, METAL FILM 18Ω, 1W - 1 1----
R20 ERG1SJ390 RESISTOR, METAL FILM 39Ω, 1W - - ----1
R20 ERG1SJ620 RESISTOR, METAL FILM 62Ω, 1W - - --1--
R20 ERG1SJ680 RESISTOR, METAL FILM 68Ω, 1W - - -1-1-
R20 EROS2CKF2000 RESISTOR, METAL FILM 200Ω, 1/4W 1 - -----
R21 ERDS2TC0 RESISTOR, CARBON FILM - 1 -----
R21 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W 1 - -----
R21 DZZZ999999 Not Mounted - - --111
R21 DZFP000149 JUMPER 5mm - - 11---
R22 DZZZ999999 Not Mounted 1 1 11111
R23 DZZZ999999 Not Mounted 1 1 11111
R24 DZZZ999999 Not Mounted 1 1 11111
R27 ERDS2TJ104 RESISTOR, CARBON FILM 100KΩ, 1/4W 1 1 11111
R28 DZZZ999999 Not Mounted 1 1 11111
R3 ERDS2TJ393 RESISTOR, CARBON FILM 39KΩ, 1/4W - - ----1
R3 ERDS2TJ683 RESISTOR, CARBON FILM 68KΩ, 1/4W - 1 111--
R3 ERDS2TJ823 RESISTOR, CARBON FILM 82KΩ, 1/4W 1 - -----
R3 ERDS2TJ224 RESISTOR, CARBON FILM 220KΩ, 1/4W - - ---1-
R30 DZFP000149 JUMPER 5mm - - 1----
R30 DZZZ999999 Not Mounted 1 - -1111
R30 ERDS2TC0 RESISTOR - 1 -----
R31 ERDS2TC0 RESISTOR - 1 -----
R31 DZFP000149 JUMPER 5mm - - 1----
R31 DZZZ999999 Not Mounted 1 - -1111
R32 DZFP000149 JUMPER 5mm - - 11111
R32 ERDS2TC0 RESISTOR 1 1 -----
or DZFP000149 JUMPER 5mm 1 - -----
or DZFP000149 JUMPER 5mm 1 - -----
R34 DZFP000149 JUMPER 5mm - - -1111
R34 DZZZ999999 Not Mounted - 1 1----
R34 ERDS2TC0 RESISTOR 1 - -----
or DZFP000149 JUMPER 5mm 1 - -----
R35 ERDS2TC0 RESISTOR 1 - -----
R35 DZFP000149 JUMPER 5mm - - -1111
R35 DZZZ999999 Not Mounted - 1 1----
R4 ERDS2TJ222 RESISTOR, CARBON FILM 2.2KΩ, 1/4W 1 1 11111
R42 DZZZ999999 Not Mounted 1 1 11111
R45 DZZZ999999 Not Mounted 1 1 1111-
R45 ERDS2TJ101 RESISTOR, CARBON FILM 100Ω, 1/4W - - ----1
R5 ERDS2TJ392 RESISTOR, CARBON FILM 3.9KΩ, 1/4W 1 1 1-1--
R5 ERDS2TJ272 RESISTOR, CARBON FILM 2.7KΩ, 1/4W - - -1---
R5 ERDS2TJ222 RESISTOR, CARBON FILM 2.2KΩ, 1/4W - - ---1-
Safety
Mark
Ref.
No.
Part Number Part Name Description
AA,AB,AD,AF
AG,AH,AJ,AM
AN,AP,AQ,AR
AS,AV,EE,YG
AE,AT,ED,YA
YB,YE,YF,YM
YN,YR,YS,YT
YU,YV,YX
AK AW YW AL YJ
