328

3.36. HTC PC Board

R23 EROS2CKF1500 RESISTOR, METAL FILM 150Ω, 1/4W - - - - - - 1

R24 EROS2CKF47R0 RESISTOR, METAL FILM 47Ω, 1/4W 1 1 1 1 1 1 -

R24 EROS2CKF15R0 RESISTOR, METAL FILM 15Ω, 1/4W - - - - - - 1

R25 ERDS2TJ333 RESISTOR, CARBON FILM 33KΩ, 1/4W 1 - - - - - -

R25 ERDS2TJ103 RESISTOR, CARBON FILM 10KΩ, 1/4W - - 1 - - 1 -

R25 ERDS2TJ473 RESISTOR, CARBON FILM 47KΩ, 1/4W - 1 - 1 1 - -

R25 ERDS2TJ513 RESISTOR, CARBON FILM 51KΩ, 1/4W - - - - - - 1

R26 ERDS2TJ123 RESISTOR, CARBON FILM 12KΩ, 1/4W - 1 1 1 1 1 1

R27 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W 1 - 1 - - 1 -

R27 ERDS2TJ274 RESISTOR, CARBON FILM 270KΩ, 1/4W - - - - 1 - -

R27 ERDS2TJ224 RESISTOR, CARBON FILM 220KΩ, 1/4W - 1 - - - - -

R27 ERDS2TJ104 RESISTOR, CARBON FILM 100KΩ, 1/4W - - - - - - 1

R27 ERDS2TJ204 RESISTOR, CARBON FILM 200KΩ, 1/4W - - - 1 - - -

R28 ERDS2TJ183 RESISTOR, CARBON FILM 18KΩ, 1/4W 1 - 1 - - 1 1

R28 ERDS2TJ752 RESISTOR, CARBON FILM 7.5KΩ, 1/4W - - - - 1 - -

R28 ERDS2TJ822 RESISTOR, CARBON FILM 8.2KΩ, 1/4W - 1 - 1 - - -

R29 ERDS2TJ183 RESISTOR, CARBON FILM 18KΩ, 1/4W 1 - 1 - - 1 1

R29 ERDS2TJ752 RESISTOR, CARBON FILM 7.5KΩ, 1/4W - - - - 1 - -

R29 ERDS2TJ822 RESISTOR, CARBON FILM 8.2KΩ, 1/4W - 1 - 1 - - -

R3 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W 1 1 1 1 1 1 1

R30 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W 1 1 1 1 1 1 1

R32 ERDS2TJ301 RESISTOR, CARBON FILM 300Ω, 1/4W 1 - - - - - -

R33 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W 1 - - - - - -

R34 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W 1 - - - - - -

R4 ERDS2TJ364 RESISTOR, CARBON FILM 360KΩ, 1/4W 1 1 1 1 1 1 1

R5 ERDS2TJ124 RESISTOR, CARBON FILM 120KΩ, 1/4W 1 1 1 1 1 1 1

R6 ERDS2TJ562 RESISTOR, CARBON FILM 5.6KΩ, 1/4W 1 - - - - - -

R7 ERDS2TC0 RESISTOR, CARBON FILM 1 1 1 1 1 1 1

or DZFP000149 JUMPER 5mm 1 - - - - - -

R8 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W 1 1 1 - 1 1 1

R9 ERDS2TJ681 RESISTOR, CARBON FILM 680Ω, 1/4W 1 - - - - - -

SW1 DZCB000002 SLIDE SWITCH 1 1 1 1 1 1 1

or DZCB000008 SLIDE SWITCH 1 1 1 1 1 1 1

SW2 DZCH000004 HOOK SWITCH 1 1 1 1 1 1 1

SW4 DZCB000003 SLIDE SWITCH 1 - - - - - -

SW4 DZCH000004 SLIDE SWITCH - 1 1 1 1 1 1

or DZCB000018 SLIDE SWITCH 1 - - - - - -

VA1 DZBM000005 METAL OXIDE VARISTOR 1 1 1 1 1 1 1

or ERZTC5AK820 SURGE ABSORBER 1 1 1 1 1 1 1

VA2 DZBM000006 METAL OXIDE VARISTOR 1 1 1 1 1 1 1

or ERZTC4AK361 SURGE ABSORBER 1 1 1 1 1 1 1

Safety

Mark

Ref. No. Part Number Part Name Description AC, AE, AU, YY Others

BA1 DZTF000004 LOCKING PLATE 1 1

C101 ECQU2A104MV CAPACITOR, FILM 0.1µF, 250VAC 1 1

C102 ECQU2A104MV CAPACITOR, FILM 0.1µF, 250VAC 1 1

C103 ECQV1H104JZ CAPACITOR, FILM 0.1µF, 50VDC 1 1

CN764-1 DZFE000010 TAB PIN 1 1

CN764-2 DZFE000010 TAB PIN 1 1

CNP760 DZFE000010 TAB PIN 1 1

CNP761 DZFE000010 TAB PIN 1 1

CNP762 DZFC000114 CONNECTOR 1 1

CNP763 DZFC000604 CONNECTOR 1 1

CNP765 DZFC000052 PH CONNECTOR 1 1

D101 DZAH000005 DIODE BRIDGE 1 1

F101 DZDW000024 FUSE 1 -

F101A DZFH000004 FUSE CLIP 1 -

F101B DZFH000004 FUSE CLIP 1 -

F102 DZDW000081 FUSE - 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

ED,YB,YE,YF

YM,YN,YR,YS

YU,YV,YX

AE AK AT YW
