327
D5 DZAH000003 DIODE 1 1 1 1 1 1 1
or DZAG000022 DIODE 1 1 1 1 1 1 1
D6 DZAH000003 DIODE 1 1 1 1 1 1 1
or DZAG000022 DIODE 1 1 1 1 1 1 1
D7 DZAH000003 DIODE 1 1 1 1 1 1 1
or DZAG000022 DIODE 1 1 1 1 1 1 1
D8 DZAH000003 DIODE 1 1 1 1 1 1 1
or DZAG000022 DIODE 1 1 1 1 1 1 1
D9 DZAH000003 DIODE 1 1 1 1 1 1 1
or DZAG000022 DIODE 1 1 1 1 1 1 1
IC1 DZAA000040 RINGER IC 1 1 1 1 1 1 1
IC2 DZAA000039 SPEECH NETWORK IC 1 1 1 1 1 1 1
JP1 ERDS2TC0 RESISTOR 1 1 1 1 1 1 1
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP2 ERDS2TC0 RESISTOR 1 1 1 1 1 1 1
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP4 ERDS2TC0 RESISTOR 1 1 1 1 1 1 1
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP5 DZZZ999999 Not Mounted 1 - - - - - -
JP6 ERDS2TC0 RESISTOR 1 - - - - - -
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP7 ERDS2TC0 RESISTOR 1 - - - - - -
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP8 ERDS2TC0 RESISTOR 1 - - - - - -
or DZFP000149 JUMPER 5mm 1 - - - - - -
JP9 ERDS2TC0 RESISTOR 1 - - - - - -
or DZFP000149 JUMPER 5mm 1 - - - - - -
L1 DZDW000108 INDUCTOR 1 - - - - - -
L1 ELEXG101KA INDUCTOR - - 1 - - - -
L1 ERDS2TC0 RESISTOR, CERAMIC - 1 - 1 1 1 1
L2 ELEXG101KA INDUCTOR 1 - 1 - - - -
L2 ERDS2TC0 RESISTOR, CERAMIC - 1 - 1 1 1 1
Q1 DZAF000022 TRANSISTOR 1 1 1 1 1 1 1
R1 DZBQ000004 RESISTOR, CARBON FILM 4.7KΩ, 1/4W 1 - - - - - -
or DZBQ000005 RESISTOR, CARBON FILM 4.7KΩ, 1/4W 1 - - - - - -
R1 ERDS2TJ472 RESISTOR, CARBON FILM 4.7KΩ, 1/4W - 1 1 1 - 1 1
R1 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W - - - - 1 - -
R10 ERDS2TJ4R7 RESISTOR, CARBON FILM 4.7Ω, 1/4W 1 - 1 1 1 1 -
R10 ERDS2TJ3R9 RESISTOR, CARBON FILM 3.9Ω, 1/4W - 1 - - - - -
R10 ERDS2TC0 RESISTOR, CARBON FILM - - - - - - 1
R11 ERDS2TJ104 RESISTOR, CARBON FILM 100KΩ, 1/4W 1 1 1 1 1 1 1
R12 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W 1 1 1 1 1 1 1
R13 ERDS2TJ750 RESISTOR, CARBON FILM 75Ω, 1/4W 1 1 1 1 1 1 1
R14 ERDS2TJ750 RESISTOR, CARBON FILM 75Ω, 1/4W 1 1 1 1 1 1 1
R15 ERDS2TJ332 RESISTOR, CARBON FILM 3.3KΩ, 1/4W 1 1 1 1 1 1 1
R17 ERDS2TC0 RESISTOR, CARBON FILM - - - - - - 1
R17 ERDS2TJ363 RESISTOR, CARBON FILM 36KΩ, 1/4W - - - - 1 1 -
R18 ERDS2TJ331 RESISTOR, CARBON FILM 330Ω, 1/4W 1 - 1 - - 1 1
R18 ERDS2TJ152 RESISTOR, CARBON FILM 1.5KΩ, 1/4W - - - - 1 - -
R18 ERDS2TJ101 RESISTOR, CARBON FILM 100Ω, 1/4W - 1 - - - - -
R18 ERDS2TC0T RESISTOR, CARBON FILM - - - 1 - - 1
R19 ERDS2TJ272 RESISTOR, CARBON FILM 2.7KΩ, 1/4W - - - 1 - - -
R19 ERDS2TJ242 RESISTOR, CARBON FILM 2.4KΩ, 1/4W 1 - 1 - - 1 -
R19 ERDS2TJ222 RESISTOR, CARBON FILM 2.2KΩ, 1/4W - 1 - - 1 - -
R19 ERDS2TJ621 RESISTOR, CARBON FILM 620Ω, 1/4W - - - - - - 1
R2 DZBQ000004 RESISTOR, CARBON FILM 4.7KΩ, 1/4W 1 - - - - - -
or DZBQ000005 RESISTOR, CARBON FILM 4.7KΩ, 1/4W 1 - - - - - -
R2 ERDS2TJ472 RESISTOR, CARBON FILM 4.7KΩ, 1/4W 1 1 1 1 - 1 1
R2 ERDS2TJ153 RESISTOR, CARBON FILM 15KΩ, 1/4W - - - - 1 - -
R20 ERDS2TJ302 RESISTOR, CARBON FILM 3KΩ, 1/4W 1 - 1 - - 1 -
R20 ERDS2TJ272 RESISTOR, CARBON FILM 2.7KΩ, 1/4W - 1 - 1 - - -
R20 ERDS2TJ222 RESISTOR, CARBON FILM 2.2KΩ, 1/4W - - - - 1 - -
R20 ERDS2TJ432 RESISTOR, CARBON FILM 4.3KΩ, 1/4W - - - - - - 1
R22 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W 1 1 1 1 1 1 1
R23 EROS2CKF4700 RESISTOR, METAL FILM 470Ω, 1/4W 1 1 1 1 1 1 -
Safety
Mark
Ref.
No.
Part Number Part Name Description
AU
AC
ED,YB,YE,YF
YM,YN,YR,YS
YU,YV,YX
YA
YT
YY
AE AK AT YW
To Next Page
