311

R246 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R247 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R248 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R249 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R25 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R250 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R251 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R252 DZZZ999999 Not Mounted 1 1 1 1

R253 DZZZ999999 Not Mounted 1 1 1 1

R254 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1

R255 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R26 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R27 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R28 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R29 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R3 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R30 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R31 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R32 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R33 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R34 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R35 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R36 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R37 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R38 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R39 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R4 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R40 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R41 DZZZ999999 Not Mounted 1 1 1 1

R42 ERJ3GEYJ752B RESISTOR, CHIP 7.5Ω, 1/16W 1 1 1 1

R43 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R44 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R45 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R46 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R47 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R48 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R49 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W 1 1 1 1

R5 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R50 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R51 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R52 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R53 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R54 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R55 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R56 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R57 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R58 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R59 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R6 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R60 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R61 ERG2SJ121 RESISTOR, METAL FILM 120Ω, 2W 1 1 1 1

R62 ERG2SJ121 RESISTOR, METAL FILM 120Ω, 2W 1 1 1 1

R63 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R64 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R65 DZZZ999999 Not Mounted 1 1 1 1

R66 DZZZ999999 Not Mounted 1 1 1 1

R67 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R68 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R69 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R7 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R70 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R71 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R72 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R73 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R74 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG,AH

AJ,AM,AN,AP,AQ,AR

AS,AV,EE,YG,YJ,YW

AE,AT,ED,YA,YB

YE,YF,YM,YN,YR

YS,YT,YU,YV,YX
