C6 OPEN
C7 EETHC2G121H CAPACITOR, ELECTROLYTIC 120µF, 400VDC
C8 ECQB1H822JF CAPACITOR, FILM 8200pF, 50VDC
C9 EEUFC1V270 CAPACITOR, ELECTROLYTIC 27µF, 35VDC
CN64 DZFC000114 CONNECTOR
CN65 DZFC000415 CONNECTOR
CN66 DZFC000014 CONNECTOR
D1 DZAH000008 DIODE
D101 DZAH000034 DIODE
D2 DZAG000033 DIODE
D3 MA700A DIODE
D4 DZAG000175 DIODE
D5 DZAG000027 DIODE
D6 DZAG000027 DIODE
F1 DZDW000084 FUSE
F2 DZDX000009 THERMAL CUTOFF
L1 ELF20N008A FILTER CHOKE
L2 EXCELDR35V BEAD INDUCTOR
L3 EXCELDR35V BEAD INDUCTOR
L4 ELF15N008A FILTER CHOKE
L5 JUMPER
L6 EXCELDR35V BEAD INDUCTOR
M1 ME33B1 MODULE
PC1 ON3171 OPTOISOLATOR
PC2 ON3171 OPTOISOLATOR
Q1 DZAF000133 FFT
Q101 2SB3311A TR
R1 ERDS1TJ474 RESISTOR, CARBON FILM 470KΩ, 1/2W
R10 ERDS1TJ681 RESISTOR, CARBON FILM 680KΩ, 1/2W
R101 ERG2SJ120 RESISTOR, METAL FILM 12Ω, 2W
R102 ERDS2TJ183 RESISTOR, CARBON FILM 18kΩ, 1/4W
R103 ERDS2TJ101 RESISTOR, CARBON FILM 100Ω, 1/4W
R104 ERDS2TJ182 RESISTOR, CARBON FILM 1.8KΩ, 1/4W
R105 ERDS2TJ562 RESISTOR, CARBON FILM 5.6kΩ, 1/4W
R106 ERG2SJ102 RESISTOR, METAL FILM 1KΩ, 2W
R107 ERDS2TJ471 RESISTOR, CARBON FILM 470Ω, 1/4W
R108 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R109 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R11 JUMPER
R110 EROS2TKF2941 RESISTOR, METAL FILM 2.91Ω, 1/4W
R111 ERDS2TJ102 RESISTOR, CARBON FILM 1KΩ, 1/4W
R12 ERG1SJ180 RESISTOR, METAL FILM 18Ω, 1W
R13 ERX12SJ5R6 RESISTOR, METAL FILM 5.6Ω, 1/2W
R14 ERDS2TJ273 RESISTOR, CARBON FILM 27KΩ, 1/4W
R15 ERG1SJ333 RESISTOR, METAL FILM 33KΩ, 2W
R17 ERG1SJ333 RESISTOR, METAL FILM 33KΩ, 2W
R18 ERDS2TJ823 RESISTOR, CARBON FILM 82KΩ, 1/4W
R19 MPC2WR15KS RESISTOR, METAL PLATE 0.15Ω, 2W
R2 ERDS2TJ683 RESISTOR, CARBON FILM 68KΩ, 1/4W
R20 JUMPER
R21 ERG2SJ100 RESISTOR, METAL FILM 10Ω, 2W
R22 ERG1SJW100 RESISTOR, METAL FILM 10Ω, 1W
Safety
Mark
Ref. No. Part Number Part Name Description
