NF2 DZDN000115 CHIP EMIFIL
NF20 DZDN000103 CHIP EMIFIL
NF21 DZDN000103 CHIP EMIFIL
NF3 DZDN000103 CHIP EMIFIL
NF4 DZDN000103 CHIP EMIFIL
NF5 DZDN000103 CHIP EMIFIL
NF6 DZDN000103 CHIP EMIFIL
NF7 DZDN000103 CHIP EMIFIL
NF8 DZDN000103 CHIP EMIFIL
NF9 DZDN000103 CHIP EMIFIL
PCB DZEP000469 PC BOARD PNL1
Q1 DZAF000042 TRANSISTOR
Q10 DZAF000042 TRANSISTOR
Q11 DZAF000042 TRANSISTOR
Q12 DZZZ999999 Not Mounted
Q13 DZZZ999999 Not Mounted
Q14 DZAF000042 TRANSISTOR
Q15 DZAF000042 TRANSISTOR
Q2 DZAF000117 TRANSISTOR
Q3 DZAF000042 TRANSISTOR
Q4 DZAF000076 PNP TRANSISTOR
Q5 DZAF000076 PNP TRANSISTOR
Q6 DZAF000042 Transistor
Q7 DZAF000042 Transistor
Q8 DZAF000042 Transistor
Q9 DZAF000042 Transistor
R1 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R10 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R100 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R101 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R102 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R103 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R104 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R105 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R106 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R107 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R108 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R11 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R12 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R13 DZZZ999999 Not Mounted
R14 DZZZ999999 Not Mounted
R15 DZZZ999999 Not Mounted
R16 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R17 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R18 DZZZ999999 Not Mounted
R19 ERJ3GEYJ681B RESISTOR, CHIP 680Ω, 1/16W
R2 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R20 DZZZ999999 Not Mounted
R21 ERJ3GEYJ301B RESISTOR, CHIP 300Ω, 1/16W
R22 ERJ3GEYJ201B RESISTOR, CHIP 200Ω, 1/16W
R23 DZZZ999999 Not Mounted
R24 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R25 ERJ14YJ332B RESISTOR, CHIP 3.3KΩ, 1/4W
R26 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R27 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R28 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R29 DZZZ999999 Not Mounted
R3 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R30 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R32 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R33 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R34 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R35 ERJ3GEYF103B RESISTOR, CHIP 10KΩ, 1/16W
R36 ERJ3GEYJ682B RESISTOR, CHIP 6.8Ω, 1/16W
R37 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R38 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
Safety
Mark
Ref. No. Part Number Part Name Description
