282
R4 DZZZ999999 Not Mounted
R49 DZZZ999999 Not Mounted
R5 DZZZ999999 Not Mounted
R54 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R55 ERJ3GEYJ682B RESISTOR, CHIP 6.8Ω, 1/16W
R56 ERJ3GEYJ221B RESISTOR, CHIP 220Ω, 1/16W
R57 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R58 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R59 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R6 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R60 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R64 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R65 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R66 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R67 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R68 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R69 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R7 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R70 DZZZ999999 Not Mounted
R71 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R74 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R75 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R76 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R77 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R78 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R79 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R8 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R80 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R81 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R82 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R83 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R84 ERJ3GEYJ102B RESISTOR, CHIP 1Ω, 1/16W
R85 DZZZ999999 Not Mounted
R86 ERJ3GEYJ104B RESISTOR, CHIP 100Ω, 1/16W
R87 ERJ3GEYJ222B RESISTOR, CHIP 2.2Ω, 1/16W
R88 ERJ3GEYJ222B RESISTOR, CHIP 2.2Ω, 1/16W
R89 ERJ3GEYJ222B RESISTOR, CHIP 2.2Ω, 1/16W
R9 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R90 ERJ3GEYJ222B RESISTOR, CHIP 2.2Ω, 1/16W
R91 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R92 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R93 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R94 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R95 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R96 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R97 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R98 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
R99 ERJ3GEYJ103B RESISTOR, CHIP 10Ω, 1/16W
RA1 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA2 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA3 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA4 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA5 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA6 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA7 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA8 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA9 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
X1 DZDP000170 CRYSTAL UNIT
X2 DZDP000171 CRYSTAL UNIT
Safety
Mark
Ref. No. Part Number Part Name Description
