Panasonic DP-3000 User Manual

291
NF27 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF28 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF29 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF3 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF30 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF31 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF32 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF33 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF34 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF35 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF36 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF4 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF5 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF6 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF7 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF8 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
NF9 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
PCB DZEP000514 PC BOARD, PRI
Q1 DZAF000044 TRANSISTOR
R1 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R10 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R11 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R12 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R13 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R14 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R15 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R16 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R17 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R18 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R19 ERJ3GEYJ105B RESISTOR, CHIP 1MΩ, 1/16W
R2 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R20 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R21 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R22 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R23 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R24 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W
R25 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R26 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R27 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R28 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R29 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R3 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W
R30 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R31 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W
R4 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R5 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W
R6 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W
R7 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W
R8 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R9 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
RA1 EXBV8V100J CHIP RESISTOR ARRAY 10Ω, 1/16W
RA2 EXBV8V100J CHIP RESISTOR ARRAY 10Ω, 1/16W
RA3 EXBV8V100J CHIP RESISTOR ARRAY 10Ω, 1/16W
RA4 EXBV8V100J CHIP RESISTOR ARRAY 10Ω, 1/16W
RA5 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
X1 DZDP000183 SERAMIC RESONATOR
Safety
Mark
Ref. No. Part Number Part Name Description
