Panasonic DP-3000 User Manual

275
C32 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C33 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C34 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C35 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C36 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C37 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C38 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C4 DZBA000187 CAPACITOR, CERAMIC 27pF, 50VDC
C5 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C6 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C7 DZZZ999999 Not Mounted
C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
CNP800 DZFC000052 PH CONNECTOR
CNP801 DZFC000047 CONNECTOR
CNP802 DZFC000016 CONNECTOR
CNP803 DZFC000017 CONNECTOR
CNP804 DZFC000548 CONNECTOR
CNP805 DZFC000052 CONNECTOR
CNP806 DZFC000101 CONNECTOR
CNP807 DZFC000650 CONNECTOR
CNP808 DZFC000690 CONNECTOR
CNP809 DZZZ999999 Not Mounted
CP1 DZDW000133 FUSE
D1 DZAH000041 DIODE
D2 DZAH000041 DIODE
D3 DZAH000041 DIODE
D4 DZAG000537 DIODE
D5 DZAG000315 SCHOTTKY BARRIER DIODE
D6 DZAG000315 SCHOTTKY BARRIER DIODE
IC1 DZAC000230 SINGLE CHIP CPU
IC3 DZAD000850 PROGRAMMED ROM, LPC
IC4 DZAA001247 MOTOR DRIVER
NF1 DZDN000123 CHIP INDUCTOR
NF2 DZDN000123 CHIP INDUCTOR
NF3 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
PCB DZEP000590 PC Board, CST3
Q1 DZAF000360 TRANSISTOR
Q2 DZZZ999999 Not Mounted
Q3 DZAF000361 TRANSISTOR
Q4 DZAF000361 TRANSISTOR
Q5 DZAF000355 NPN SILICON TRANSISTOR
Q6 DZAF000355 NPN SILICON TRANSISTOR
Q7 DZAF000197 TRANSISTOR
R1 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R10 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
R11 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R12 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R13 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R14 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R15 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R16 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R17 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R18 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R19 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R2 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R20 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R21 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R22 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R23 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R24 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R25 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R26 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R27 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R28 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R29 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R3 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
Safety
Mark
RefNo Part Number Part Name Description
