RA116 DZZZ999999 Not Mounted
RA117 DZZZ999999 Not Mounted
RA118 DZZZ999999 Not Mounted
RA119 DZZZ999999 Not Mounted
RA12 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA120 DZZZ999999 Not Mounted
RA121 DZZZ999999 Not Mounted
RA122 DZZZ999999 Not Mounted
RA123 DZZZ999999 Not Mounted
RA124 DZZZ999999 Not Mounted
RA13 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA130 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA131 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA132 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA133 EXBV8V100J CHIP RESISTOR ARRAY 10Ω, 1/16W
RA134 DZZZ999999 Not Mounted
RA135 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
RA14 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA15 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA16 EXBV8VR000 CHIP RESISTOR ARRAY (JUMPER) 0Ω, 1/16W
RA17 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
RA18 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
RA19 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
RA2 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA20 EXBV8V104J CHIP RESISTOR ARRAY 100KΩ, 1/16W
RA21 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA22 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA23 DZDN000130 EMI FILTER
RA24 DZDN000130 EMI FILTER
RA25 DZDN000130 EMI FILTER
RA26 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA27 DZZZ999999 Not Mounted
RA28 EXBV8V102J CHIP RESISTOR ARRAY 1KΩ, 1/16W
RA29 EXBV8V102J CHIP RESISTOR ARRAY 1KΩ, 1/16W
RA3 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA30 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA31 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA32 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA33 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA35 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA36 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA37 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA38 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA39 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA4 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA40 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA41 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA42 EXBV8V103J CHIP RESISTOR ARRAY 10KΩ, 1/16W
RA43 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA44 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA45 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA46 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA47 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA48 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA49 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA5 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA50 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA51 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA52 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA53 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA54 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA55 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA56 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA57 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA58 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
RA59 EXBV8V330J CHIP RESISTOR ARRAY 33Ω, 1/16W
Safety
Mark
Ref. No. Part Number Part Name Description
