D401 DZAH000041 FUSE
D402 MA152A-(TX) FUSE
D404 DZZZ999999 Not Mounted
D405 MA153A-(TX) DIODE
D406 MA153A-(TX) DIODE
D601 DZAH000041 DIODE
D602 MA153A-(TX) DIODE
D801 DZAH000041 DIODE
D802 DZAH000041 DIODE
D803 MA152A-(TX) DIODE
D804 MA152A-(TX) DIODE
IC101 DZAA001711 SINGLE CHIP CPU
IC102 DZAD000822 PROGRAMMED ROM, LPC
IC200 DZAC000020 GATE ARRAY
IC301 DZAA002077 RESETTING IC
IC302 DZZZ999999 Not Mounted
IC401 DZAA002010 COMPARATOR
IC402 DZAA002032 3-TERMINAL POSITIVE VOLTAGE REGULATOR
IC403 DZAF000364 TRANSISTOR ARRAY
IC404 DZAA002092 TRIPLE INVERTER
IC701 DZAA001984 OP AMP
IC702 DZAA002070 TRIPLE INVERTER
IC703 DZAA002126 DUAL BUS BUFFER
LED1 DZAG000513 LED
NF101 DZDN000116 CHIP EMIFIL
NF301 DZDN000116 CHIP EMIFIL
NF302 DZDN000116 CHIP EMIFIL
NF701 DZDN000116 CHIP EMIFIL
NF702 DZDN000095 CHIP INDUCTOR
PCB DZEP000587 PC Board, LPC
Q101 DZAF000197 TRANSISTOR
Q302 DZAF000361 TRANSISTOR
Q303 DZAF000359 DIGITAL TRANSISTOR
Q304 DZAF000361 TRANSISTOR
Q305 DZAF000361 TRANSISTOR
Q306 DZAF000348 DIGITAL TRANSISTOR
Q307 DZAF000347 NPN SILICON TRANSISTOR
Q308 DZAF000361 TRANSISTOR
Q403 DZAF000350 PNP TRANSISTOR
Q404 DZAF000350 PNP TRANSISTOR
Q405 DZAF000361 TRANSISTOR
Q406 DZAF000361 TRANSISTOR
Q407 DZAF000361 TRANSISTOR
Q408 DZAF000361 TRANSISTOR
Q411 DZAF000388 FET
Q412 DZAF000366 DIGITAL TRANSISTOR
Q413 DZAF000361 TRANSISTOR
Q414 DZAF000361 TRANSISTOR
Q415 DZAF000361 TRANSISTOR
Q603 DZAF000197 TRANSISTOR
Q604 DZAF000361 TRANSISTOR
Q605 DZAF000361 TRANSISTOR
Q606 DZAF000372 POWER MOSFET
Q607 DZAF000361 TRANSISTOR
Q701 DZAF000361 TRANSISTOR
Q702 DZAF000361 TRANSISTOR
Q703 DZAF000361 TRANSISTOR
Q704 DZAF000361 TRANSISTOR
Q705 DZAF000361 TRANSISTOR
Q706 DZAF000347 NPN SILICON TRANSISTOR
Q801 DZAF000197 TRANSISTOR
Q802 DZAF000197 TRANSISTOR
R101 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R103 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R104 DZZZ999999 Not Mounted
R105 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
Safety
Mark
Ref. No. Part Number Part Name Description
To Next Page
