301
C67 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C68 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C69 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C70 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C71 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C72 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C73 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C74 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C75 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C76 DZZZ999999 Not Mounted
C77 EEVHA1E220 CAPACITOR, ELECTROLYTIC 22µF, 25VDC
C78 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C79 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C80 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
CNP1 DZFC000337 CONNECTOR
CNP2 DZZZ999999 Not Mounted
CNP4 DZFC000310 CONNECTOR
CNP5 DZZZ999999 Not Mounted
DSW1 DZZZ999999 Not Mounted
IC1 DZAA000751 CMOS
IC10 DZAA000823 DRAM
IC11 DZAA000823 DRAM
IC12 DZAA000823 DRAM
IC13 DZAA000823 DRAM
IC15 DZAA000752 CMOS
IC16 DZAA000835 CMOS
IC17 DZZZ999999 Not Mounted
IC18 DZZZ999999 Not Mounted
IC19 DZAA000755 CMOS
IC2 DZAA000829 16BIT BUS BUFFER/DRIVER
IC20 DZAA000755 CMOS
IC3 DZAA001175 CPU
IC4 DZAA000747 REGULATOR
IC5 DZAA000829 16BIT BUS BUFFER/DRIVER
IC6 DZAC000214 FPGA
IC7 DZAA000825 16BIT BUS TRANSCEIVER
IC8 DZAA000825 16BIT BUS TRANSCEIVER
IC9 DZAA000691 DUAL PORT RAM
LED1 DZAG000068 LED
LED2 DZAG000068 LED
LED3 DZAG000068 LED
LED4 DZAG000068 LED
NF1 DZDN000010 CHIP INDUCTOR
NF2 DZDN000095 CHIP INDUCTOR
NF3 DZDN000095 CHIP INDUCTOR
OSC1 DZDP000115 CRYSTAL UNIT
or DZDP000197 CRYSTAL UNIT
PCB DZEP000411 PC BOARD, EP
R1 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R10 ERJ3GEYJ471B RESISTOR, CHIP 470Ω, 1/16W
R11 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R110 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R111 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R112 DZZZ999999 Not Mounted
R113 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R114 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R115 DZZZ999999 Not Mounted
R116 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R117 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R118 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R119 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R12 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R120 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
Safety
Mark
Ref. No. Part Number Part Name Description
