314

C64 DZZZ999999 Not Mounted 1

C65 DZZZ999999 Not Mounted 1

C66 DZZZ999999 Not Mounted 1

C67 DZZZ999999 Not Mounted 1

C68 DZZZ999999 Not Mounted 1

C69 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C70 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C71 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C72 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C73 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C74 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C75 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C76 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C77 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C78 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C79 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C80 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C81 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C82 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C83 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C84 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C85 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC 1

C86 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC 1

C87 EEVHA1C100 CAPACITOR, ELECTROLYTIC 10µF, 16VDC 1

C88 DZBA000005 CAPACITOR, CERAMIC 1

C89 DZBA000010 CAPACITOR, CERAMIC 1

C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C90 DZBA000021 CAPACITOR, CERAMIC 1

C92 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC 1

C93 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC 1

C94 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C95 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1

C96 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C97 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

C98 DZBA000206 CAPACITOR, CERAMIC 0.1µF, 16VDC 1

C99 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1

CNJ1 DZZZ999999 Not Mounted 1

CNP2 DZFC000586 2PIECE CONNECTOR 1

CNP3 DZZZ999999 Not Mounted 1

CNP4 DZZZ999999 Not Mounted 1

CNP5 DZFC000340 PH CONNECTOR 1

CNP6 DZFC000389 PH CONNECTOR 1

D1 DZAG000116 SWITCHING DIODE 1

D2 DZAG000116 SWITCHING DIODE 1

D3 DZAG000116 SWITCHING DIODE 1

D4 DZAG000116 SWITCHING DIODE 1

IC1 DZAA000434 VHCMOS 1

IC10 DZZZ999999 Not Mounted 1

IC11 DZAA000091 AND GATE 1

IC12 DZAA000691 DUAL PORT RAM 1

IC13 DZAA000091 AND GATE 1

IC14 DZAA000432 VHCMOS 1

IC15 DZAA000432 VHCMOS 1

IC16 DZAA000434 VHCMOS 1

IC17 DZAA000595 VHCMOS 1

IC18 DZAA000091 AND GATE 1

IC19 DZZZ999999 Not Mounted 1

IC2 DZAC000217 MASK CPU7041SH 1

IC2 DZAD000451 PROGRAMMED CPU 1

IC20 DZAA000509 VHCMOS 1

IC21 DZAA000595 VHCMOS 1

IC22 DZAA000560 VHCMOS 1

IC23 DZAA000432 VHCMOS 1

IC24 DZAA000432 VHCMOS 1

Safety

Mark

Ref. No. Part Number Part Name Description

AB, AC, AF, AG, AK, AL

AQ, AU, AV, EE, YW, YX
