1.2.2. Printer Initial Flow Chart
SC Initial End
Hard Reset
Start Watching I/O Port
IC200
Pin70
IC101 Pin93
Vin < 1.0V
STOP
No Cartridge
Front Door Open
STOP
Y
L
H
IC101 Pin94
Vin < 1.0V
Right Cover Open
STOP
N
IC200
Pin64
Regist Sensor ON
STOP
L
N
IC200
Pin65
Exit Sensor ON
STOP
L
H
IC200
Pin39
2nd JAM Cover Open
STOP
L
H
IC200
Pin83
2nd Prefeed Sensor ON
STOP
L
H
CST3 IC1
Pin27
3rd JAM Cover Open
STOP
L
H
CST3 IC1
Pin28
3rd Prefeed Sensor ON
STOP
When
3rd Paper Tray
is installed
L
H
B
Y
