Panasonic DVCPRO AJ-CA901P - Page 46

Components identified with the mark  have special characteristics for safety.
When replacing any of these component, use only the same type.
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
IC43 C1AB00001136 IC 1 R58 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K 1
IC45 C1AB00000367 IC 1 R59 ERJ3RBD301 M.RESISTOR CH 1/16W 300 1
IC46 C0JBAA000115 IC 1 R60 ERJ3RBD102 M.RESISTOR CH 1/16W 1K 1
IC47 C1AB00001136 IC 1 R61 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
IC48 MN64672 IC 1 R62 ERJ3RBD152 M.RESISTOR CH 1/16W 1.5K 1
IC49,50 TL062CPW IC 2 R63 ERJ3RBD362 M.RESISTOR CH 1/16W 3.6K 1
IC54 TC7SH04FU IC 1 R64 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 1
IC55 C0EBH0000053 IC 1 R65,66 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002
IC56 C0JBAA000076 IC 1 R67 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R68 ERJ3GEYJ683 M.RESISTOR CH 1/16W 68K 1
IP32 VSI3719 IC 1 R69 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K 1
R70 ERJ3RBD302 M.RESISTOR CH 1/16W 3K 1
J1 VJS3307 CONNECTOR (FEMALE) 1 K1QZB1AB0001 R71 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R72 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1
L1-L3 J0JBC0000041 FILTER 3 R73-75 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 3
L4 J0JKC0000009 FILTER 1 R76 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
L5-18 J0JBC0000041 FILTER 14 R77 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 1
L19 VLQ0163J470 COIL 47UH 1 R78 ERJ3GEYJ333 M.RESISTOR CH 1/16W 33K 1
L21 VLQ0163J330 COIL 33UH 1 G1C330J00004 R79 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
L22 J0JBC0000041 FILTER 1 R80 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1
L23,24 ELJRE8N2JF2 COIL 2 R81 ERJ3GEYJ241 M.RESISTOR CH 1/16W 240 1
L25,26 J0JBC0000041 FILTER 2 R82 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
L27 VLQ0171KR22N COIL 0.22UH 1 G0CR22KA0025 R83 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 1
R84 ERJ3RBD153 M.RESISTOR CH 1/16W 15K 1
P1 VJP4064Q160 CONNECTOR (MALE) 1 K1KBG0B00002 R85 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K 1
P2 VJP4395D007 CONNECTOR (MALE) 1 R86 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K 1
R87 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
Q1-Q3 2SK316-Q TRANSISTOR 3 2SK03160Q R88 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
Q4 2SB09560HL TRANSISTOR 1 R89,90 ERJ3RBD103 M.RESISTOR CH 1/16W 10K 2
Q5 2SD1280 TRANSISTOR 1 R91 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
Q6 2SB09560HL TRANSISTOR 1 R92 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
Q7-Q9 UN2215 TRANSISTOR-RESISTOR 3 R93 ERJ3RBD303 M.RESISTOR CH 1/16W 30K 1
Q10 2SA1461Y24 TRANSISTOR 1 R94 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1
Q11 2SD0601ARL TRANSISTOR 1 R95 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K 1
Q13-15 UN2215 TRANSISTOR-RESISTOR 3 R102-07 EXB24V473J COMBI.R-R 47K 6
Q16 UN5212 TRANSISTOR-RESISTOR 1 R108-11 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 4
R112,13 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 2
R3,R4 EXB24V473J COMBI.R-R 47K 2 R116 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 1
R7,R8 EXB24V473J COMBI.R-R 47K 2 R120,21 EXB24V473J COMBI.R-R 47K 2
R11,12 EXB24V473J COMBI.R-R 47K 2 R122,23 EXB24V101J COMBI.R-R 100 2
R15,16 EXB24V473J COMBI.R-R 47K 2 R124 EXB24V473J COMBI.R-R 47K 1
R19,20 EXB24V473J COMBI.R-R 47K 2 R126 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R21 ERJ3RBD301 M.RESISTOR CH 1/16W 300 1 R127 ERJ3GEYJ162 M.RESISTOR CH 1/16W 1.6K 1
R22 ERJ3RED510 M.RESISTOR CH 1/16W 51 1 R128 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 1
R23 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K 1 R129 ERJ3GEYJ202 M.RESISTOR CH 1/16W 2K 1
R25 ERJ3RBD331 M.RESISTOR CH 1/16W 330 1 R130 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1
R26 ERJ3RBD102 M.RESISTOR CH 1/16W 1K 1 R131 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R27 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R132 ERJ3GEYJ512 M.RESISTOR CH 1/16W 5.1K 1
R28 ERJ3RBD112 M.RESISTOR CH 1/16W 1.1K 1 R133 ERJ3GEYJ751 M.RESISTOR CH 1/16W 750 1
R29 ERJ3GEYJ823 M.RESISTOR CH 1/16W 82K 1 R134 ERJ3GEYJ201 M.RESISTOR CH 1/16W 200 1
R30,31 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002 R136 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R32 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1 R137 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R33 ERJ3GEYJ623 M.RESISTOR CH 1/16W 62K 1 R138 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1
R34 ERJ3RBD202 M.RESISTOR CH 1/16W 2K 1 R139 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R35 ERJ3RBD302 M.RESISTOR CH 1/16W 3K 1 R140-42 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 3
R36 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R143-45 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 3 D0GB103JA002
R38 ERJ3RBD301 M.RESISTOR CH 1/16W 300 1 R146 ERJ3GEYJ151 M.RESISTOR CH 1/16W 150 1
R39 ERJ3RED510 M.RESISTOR CH 1/16W 51 1 R147 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R40 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K 1 R148 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R41 ERJ3RBD332 M.RESISTOR CH 1/16W 3.3K 1 R149 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1
R42 ERJ3RBD301 M.RESISTOR CH 1/16W 300 1 R150 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R43 ERJ3RBD102 M.RESISTOR CH 1/16W 1K 1 R151-53 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 3
R44 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R154-56 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 3 D0GB103JA002
R45 ERJ3RBD152 M.RESISTOR CH 1/16W 1.5K 1 R157 ERJ3GEYJ151 M.RESISTOR CH 1/16W 150 1
R46 ERJ3RBD362 M.RESISTOR CH 1/16W 3.6K 1 R158 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R47 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 1 R159 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R48,49 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 2 D0GB103JA002 R160 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1
R50 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1 R161 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
R51 ERJ3GEYJ683 M.RESISTOR CH 1/16W 68K 1 R162-64 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 3
R52 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K 1 R165-67 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 3 D0GB103JA002
R53 ERJ3RBD302 M.RESISTOR CH 1/16W 3K 1 R168 ERJ3GEYJ151 M.RESISTOR CH 1/16W 150 1
R54 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 R169 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002
R55 ERJ3RBD301 M.RESISTOR CH 1/16W 300 1 R170 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1
R56 ERJ3RED510 M.RESISTOR CH 1/16W 51 1 R171 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1
R57 ERJ3RBD752 M.RESISTOR CH 1/16W 7.5K 1 R172 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 1
EPL-3
