Panasonic DVCPRO AJ-CA901P - Page 47

Components identified with the mark  have special characteristics for safety.
When replacing any of these component, use only the same type.
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
R173-75 ERJ3GEYG682 M.RESISTOR CH 1/16W 6.8K 3 C18,19 VCEA1AAP221 E.CAPACITOR 10V 220U 2 F2D1A2210001
R176-78 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 3 D0GB103JA002 C20,21 EEUFC1V151 E.CAPACITOR 35V 150P 2
R179 ERJ3GEYJ151 M.RESISTOR CH 1/16W 150 1 C22 ECUX1H151JCV C.CAPACITOR CH 50V 150P 1
R180-84 EXB24V101J COMBI.R-R 100 5 C23,24 VCEA1AAP221 E.CAPACITOR 10V 220U 2 F2D1A2210001
R185 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100 1 C25-27 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
R187 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C28,29 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2
R188 ERJ3GEYJ391 M.RESISTOR CH 1/16W 390 1 C30,31 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
R189 ERJ3GEYJ470 M.RESISTOR CH 1/16W 47 1 C32,33 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2
R191 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C34-37 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 4
R192-96 ERJ3GEYJ750 M.RESISTOR CH 1/16W 75 5 C38 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
R197-01 ERJ3GEYJ303 M.RESISTOR CH 1/16W 30K 5 C39,40 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
R202 ERJ3GEYJ100 M.RESISTOR CH 1/16W 10 1 C41 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 1
R203 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K 1 D0GB103JA002 C42 ECST1VC685 T.CAPACITOR CH 35V 6.8U 1
R204,05 ERJ3GEYJ432 M.RESISTOR CH 1/16W 4.3K 2 C43 ECST1EC106 T.CAPACITOR CH 25V 10U 1
R206,07 ERJ3GEYJ162 M.RESISTOR CH 1/16W 1.6K 2 C44,45 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
R208,09 ERJ3GEYJ223 M.RESISTOR CH 1/16W 22K 2 C46 ECST1CY335ZR T.CAPACITOR CH 16V 3.3U 1
R210 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 1 C47,48 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
R211-13 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 3 C49 ECST1VC685 T.CAPACITOR CH 35V 6.8U 1
R214 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C51 ECST1CC226Z T.CAPACITOR CH 16V 22U 1
R215,16 ERJ3GEYJ432 M.RESISTOR CH 1/16W 4.3K 2 C52 ECUX1H100DCV C.CAPACITOR CH 50V 10P 1
R217,18 ERJ3GEYJ162 M.RESISTOR CH 1/16W 1.6K 2 C53,54 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
R219,20 ERJ3GEYJ223 M.RESISTOR CH 1/16W 22K 2 C55 ECUX1H100DCV C.CAPACITOR CH 50V 10P 1
R221 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K 1 C56-58 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 3
R222-24 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 3 C60,61 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 2
R225 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 1 C62,63 ECUX1H101JCV C.CAPACITOR CH 50V 100P 2
R249 ERJ3GEYJ330 M.RESISTOR CH 1/16W 33 1 C64 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
R250 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1 C65 ECST1CC226Z T.CAPACITOR CH 16V 22U 1
R251 ERJ3GEYJ203 M.RESISTOR CH 1/16W 20K 1 C66-70 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 5
R252 ERJ3GEYJ473 M.RESISTOR CH 1/16W 47K 1 C71 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
R254,55 ERJ3GEYG102 M.RESISTOR CH 1/16W 1K 2 C72 ECJ1VC1H560J C.CAPACITOR CH 50V 560P 1
R258,59 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0 2 C73,74 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 2
C75 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
SW1 CAS-120B SWITCH 1 C76 ECST1VC685 T.CAPACITOR CH 35V 6.8U 1
C77 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
TP1-P3 EYF6CU TEST POINT 3 C78 ECST1VC685 T.CAPACITOR CH 35V 6.8U 1
C79 ECUX1A105ZFV C.CAPACITOR CH 10V 1U 1
VR1 VRV0303B500A V.RESISTOR 50 1 C80 ECUX1H101JCV C.CAPACITOR CH 50V 100P 1
VR2 VRV0303B502 V.RESISTOR 5K 1 C81,82 ECST1CC226Z T.CAPACITOR CH 16V 22U 2
VR3 VRV0303B500A V.RESISTOR 50 1 C108 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1
VR4 VRV0303B502 V.RESISTOR 5K 1 C110 ECST1CC226Z T.CAPACITOR CH 16V 22U 1
VR5 VRV0303B500A V.RESISTOR 50 1 C112,13 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 2
VR6 VRV0303B502 V.RESISTOR 5K 1 C114,15 ECST1CY685Z T.CAPACITOR CH 16V 6.8U 2
C116 ECSF1AE336 T.CAPACITOR CH 10V 33U 1
X1 VSX0670 CRYSTAL OSCILLATOR 1 H1C3605A0002
D1-D6 MA152WK DIODE 6
MISCELLANEOUS D7 MA3180 DIODE 1
D8 EA60QC04F DIODE 1 B0JDRE000002
VSC5322 HEAT SINK 1 D9 MA3062 DIODE 1
VMT1231 THERMAL CONDUCTIVE 1 1 D10 MA3180 DIODE 1
XYN2+J6 SCREW 4 D11 EA60QC04F DIODE 1 B0JDRE000002
VMX3203 SPACER 2 D12 MAZ306800L DIODE 1
VMS7112 SPACER 1 D13-16 MA3047 DIODE 4
XYN3+K6 SCREW 1 D17 B0JCML000002 DIODE 1
IC1 TL062CPW IC 1
IC2 TL1451CNS IC 1 C0DBAMA00001
IC3 NJM431U IC 1 C0DBEZC00003
IC4,C5 TL062CPW IC 2
 E3
VEP21250A CAM POWER P.C.BOARD 1 (RTL) IC6 NJM431U IC 1 C0DBEZC00003
IC7 C0ABEB000023 IC 1
IC8 NJM4560MD IC 1 C0ABBB000116
C1 ECUX1H102JCV C.CAPACITOR CH 50V 1000P 1 IC9 MCD5223 IC 1 B3RAC0000004
C2 ECST1VC685 T.CAPACITOR CH 35V 6.8U 1 IC10 C0ABBA000075 IC 1
C3 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 IC11 MCD5223 IC 1 B3RAC0000004
C4 ECST1CD686 T.CAPACITOR CH 16V 68U 1 IC12 TL062CPW IC 1
C5 ECST1CX106Z T.CAPACITOR CH 16V 10U 1 IC13,14 TC4W53FU IC 2
C7 ECUX1H182KBV C.CAPACITOR CH 50V 1800P 1 IC15 C0ABEB000023 IC 1
C9 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 IC16 TC4W53FU IC 1
C10 ECUX1H471JCV C.CAPACITOR CH 50V 470P 1 IC17 C0ABEB000023 IC 1
C11 ECUX1H332KBV C.CAPACITOR CH 50V 3300P 1 IC18 NJM4560MD IC 1 C0ABBB000116
C12 ECST0JX336 T.CAPACITOR CH6.3V 33U 1 IC29 C0ABEB000023 IC 1
C13 ECUX1H471JCV C.CAPACITOR CH 50V 470P 1
C14 ECJ1VF1E104Z C.CAPACITOR CH 25V 0.1U 1 L1 VLQ0417 COIL 10UH 1
C16 EEUFC1V151 E.CAPACITOR 35V 150P 1 L2 J0JKC0000009 FILTER 1
C17 ECUX1H151JCV C.CAPACITOR CH 50V 150P 1 L3 VLQ0400 COIL 1
EPL-4
