With other products
78
VQT1H64
≥ Use the AC adaptor to free you from worrying about the battery running down.
1 Connect this unit and a TV with the HDMI cable (optional).
Use a HDMI cable (optional) A with the logo shown above.
2 Set the mode dial to to turn on the power.
3 Select the input channel on the TV.
Example:
Select the [HDMI] channel etc.
(The name of the channel may differ depending on the connected TV.)
4 Start playback on this unit.
The image and audio are output on the TV.
ª If the image or audio from this unit is not output on the TV
≥ Check that the plugs are inserted as far as they go.
≥ Check the connected terminal.
≥ Check the input setting (input switch) and the audio input setting on the TV. (For more
information, please read the operating instructions for the TV.)
≥ Check [HDMI RESOLUTION]. (l 79)
1 Connecting with a HDMI cable (optional)
What is HDMI?
HDMI is the next-generation interface for digital devices. When this unit is connected to a HDMI
compatible device, the image and audio can be output with a digital signal. If you connect this unit
and a HDMI compatible high definition TV and then play back the recorded high definition images
(l 8), you can enjoy them in high resolution with high quality sound.
If you connect this unit to a Panasonic TV (VIERA) compatible with VIERA Link (HDAVI
Control), linked operations are possible. (l 83)
HDMI IN
