4.3 Installing the Unit
1. Remove all packing tapes.
2. Open the feed tray
.
3. Remove the shipping screw ( ).
Location of the shipping screw
2
1
• The ADF door will not open unless you remove the shipping screw.
Notice
• Store the removed shipping screw in the accessory box ( ).
4. Open the ADF door (page
33).
5. Remove all tape and cushioning.
