Chapter 3 Basic Operations — Projecting
52 - ENGLISH
Adjusting the projection
Adjust focus and zoom.
1) Press the <FOCUS> or <ZOOM> button on the remote control.
f <FOCUS> button: Adjusts focus.
f <ZOOM> button: Adjusts zoom.
2) Select each item and press asqw to adjust it.
Note
f When a projection position is required to be adjusted, adjust according to the steps described in “Adjusting the projection position”
(x page 38).
f The operation can be sped up by pressing asqw for at least one second.
f Only [FOCUS] is shown in yellow so that the displayed menu item can be recognized by color, even when the projector is not focused and
displayed characters are unreadable.
f The projection lens is thermally affected by the light from the light source, making the focus unstable in the period just after switching on the
power. It is recommended that images be projected continuously for at least 30 minutes before the focus is adjusted.
