25.1. Component Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0139 21P FFC CABLE (DECK-MAIN) [M]
2 REEX0740 10P FFC CABLE (MUSIC-MN) [M]
4 REEX0881 17P FFC CABLE (MAIN-DAMP) [M]
6 REEX0883 27P FFC CABLE (MAIN-PANEL) [M]
7 REXX0681 2P WIRE (USB-MAIN) [M]
8 REEX0904 11P FFC CABLE (MAIN-CD) [M]
9 RDGX0040 VOLUME GEAR [M]
10 RGCX0010A-W LIGHT REFLECTOR [M]
11 RFKGAVK470GC FRONT PANEL ASS´Y [M]
12 RGKX0482-S VOLUME ORNAMENT [M]
13 RGKX0483A-K1 CD LID [M]
14 RGKX0488A-B DYNAMIC BASS ORNAMENT [M]
15 RGLX0164-Q VOLUME BASS ORNAMENT [M]
16 RGLX0167-Q POWER LIGHT PIECE [M]
17 RXQX0084A HDMI SHIELD PLATE UNIT [M]
18 RGRX0070L-B REAR PANEL [M]
20 RGUX0764A-S FUNCTION BUTTON L [M]
21 RGUX0765-S DYNAMIC BASS BUTTON [M]
22 RGUX0766A-K 5CD CHANGE BUTTON [M]
23 RGUX0767B-K POWER LIGHT PIECE [M]
24 RGUX0768-K CASSETTE EJECT BUTTON [M]
25 RGUX0777A-S FUNCTION BUTTON R [M]
26 RGWX0056-1K MIC VOLUME KNOB [M]
27 RGWX0072A-1S VOLUME KNOB [M]
29 RHD26046-L SCREW [M]
30 RHD30007-K2J SCREW [M]
31 RHD30070 EARTH TERMINAL SCREW [M]
32 RHD30111-3 SCREW [M]
33 RHD30119-S SCREW [M]
34 RKA0072-KJ LEG CUSHION [M]
35 RKFX0143A-K1 CASS LID [M]
36 RKMX0144-K TOP CABINET [M]
37 RSCX0196 GROUND GEAR [M]
38 RMAX0333 CHASSIS SUPPORT [M]
39 RMBV0042-2 CASSETTE LID SPRING [M]
40 RMBX0086 CD LID OPEN SPRING [M]
41 RMC0465 TR SPRING [M]
42 RMGX0033 CUSHION RUBBER [M]
43 RMKX0151 CD CHASSIS [M]
44 RMKX0148 BOTTOM CHASSIS [M]
45 RMKX0149 INNER CHASSIS [M]
46 RMNV0059 LED HOLDER [M]
47 RMNV0079-1 FL HOLDER [M]
49 RMVX0119 BARRIER COVER [M]
50 RXXX0105 HEATSINK UNIT C [M]
52 RMZX0041 IC INSULATOR SHEET [M]
53 RHD30008 SCREW [M]
54 RMNX0287 USB JACK HOLDER [M]
55 RMNX0190 LED HOLDER [M]
56 RUS757ZAA CASSETTE HALF SPRING [M]
57 RXGX0002 DAMPER GEAR [M]
58 RXXX0085A-1J HEAT SINK UNIT A [M]
59 RXXX0104A HEAT SINK UNIT B [M]
60 XTB3+10JFJ SCREW [M]
61 RWJ1108055SS 8P WIRE (PANEL - TACT) [M]
62 XTV3+10GFJ-M SCREW [M]
63 XTW3+12TFJ SCREW [M]
64 XTW3+8TFJ SCREW [M]
66 REXX0690 5P SHIELD WIRE (BE-USB) [M]
68 REXX0684 BLACK WIRE [M]
69 REXX0685 RED WIRE [M]
72 REXX0683 8P WIRE (SMPS-DAMP) [M]
74 REEX0905 50P FFC CABLE (MAIN-BE) [M]
CASSETTE DECK
101 RED0064-2 R/P HEAD BLOCK UNIT [M]
103 RDG0300 REEL BASE GEAR [M]
104 RDG0301 WINDING RELAY GEAR [M]
Ref.
No.
Part No. Part Name & Description Remarks
105 RDK0026-4 MAIN GEAR [M]
107 RDV0033-4 WINDING BELT [M]
108 RDV0034-2 CAPSTAN BELT A [M]
110 RMB0312 TRIGGER LEVER SPRING [M]
111 RMB0400 REEL SPRING [M]
112 RMB0403 HEAD PANEL SPRING [M]
113 RMB0404 BRAKE ROD SPRING [M]
114 RMB0406-5 FR LEVER SPRING [M]
115 RMB0408 THRUST SPRING [M]
116 RML0370-4 TRIGGER LEVER [M]
117 RML0371 FR LEVER [M]
118 RML0372-2 WINDING LEVER [M]
119 RML0374-2 EJECT LEVER [M]
120 RMM0131-1 BRAKE ROD [M]
121 RMM0133-1 EJECT ROD [M]
122 RMQ0519 REEL HUB [M]
123 RMS0398-1 MOVING CORE [M]
124 RSJ0003 SOLENOLD ASS´Y [M]
125 RMC0061 PACK SPRING [M]
126 RXF0061-1 FLYWHEEL F ASS´Y [M]
127 RXF0062-1 FLYWHEEL R ASS´Y [M]
128 RXG0040 FF RELAY GEAR ASS´Y [M]
129 RMK0283A-2 SUB-CHASSIS [M]
130 RXL0124 PINCH ROLLER F ASS´Y [M]
130-1 RMB0401 PINCH ARM SPRING F [M]
131 RXL0125 PINCH ROLLER R ASS´Y [M]
131-1 RMB0402 PINCH ARM SPRING R [M]
132 RXL0126 WINDING ARM ASS´Y [M]
133 RXQ0412-3 HEAD PANEL ASS´Y [M]
133-1 RMB0405-1 FR ROD SPRING [M]
133-2 RMM0132-2 FR ROD [M]
134 REM0120 CAP MOTOR ASS´Y [M]
135 RHD26022-1 MOTOR SCREW [M]
136 XTW2+5LFJ HEAD BLOCK UNIT SCREW [M]
137 XTW26+10SFJ SUB-CHASSIS SCREW [M]
138 XYC2+JF17FJ PCB EARTH SCREW [M]
139 RFKJSTR280PP MAIN CHASSIS ASS´Y [M]
PACKING MATERIALS
P1 RPGX1941 PACKING CASE [M]
P2 RPNX0548 POLYFOAM [M]
P3 RPFX0198 MIRAMAT [M]
ACCESSORIES
A1 N2QAYB000266 REMOTE CONTROL [M]
A1-1 RKK-HTR0051K R/C BATTERY COVER [M]
A2 K2CQ2CA00007 AC CORD [M]
A3 RQTV0313-R O/I BOOK (Ru/Ur) [M]
A4 RSA0007-L1 FM INDOOR ANTENNA [M]
A5 N1DYYYY00003 AM LOOP ANTENNA [M]
A6 K2KA2CA00011 VIDEO CABLE [M]
A7 RP-VK21E-K MICROPHONE [M]
PRINTED CIRCUIT BOARDS
PCB1 REPX0321K DECK MECHANISM P.C.B [M]
(RTL)
PCB2 REPX0411D DECK P.C.B [M]
(RTL)
PCB3 REPX0620F-M DVD MODULE P.C.B [M]
(RTL)
PCB4 REPX0622Y SMPS P.C.B [M]
(RTL)
PCB5 REPX0622Y AC INLET P.C.B [M]
(RTL)
PCB6 REPX0638G D-AMP P.C.B [M]
(RTL)
PCB7 REPX0658C MAIN P.C.B [M]
(RTL)
PCB8 REPX0658C USB P.C.B [M]
(RTL)
142
SA-VK470EE
