Ref.
No.
Part No. Part Name & Description Remarks
PCB9 REPX0671A PANEL P.C.B [M]
(RTL)
PCB10 REPX0671A TACT SWITCH P.C.B [M]
(RTL)
PCB11 REPX0671A SIDE BAR (R) LED P.C.B [M]
(RTL)
PCB12 REPX0671A SIDE BAR (L) LED P.C.B [M]
(RTL)
PCB13 REPX0671A REMOTE SENSOR P.C.B [M]
(RTL)
PCB14 REPX0671A MIC P.C.B [M]
(RTL)
PCB15 REPX0671A MUSIC PORT P.C.B [M]
(RTL)
INTEGRATED CIRCUITS
IC971 CNB13030R2AU IC PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SWITCH [M]
IC1001 AN7326K IC DECK R/P [M]
IC2002 C0CBCBC00140 IC VOLTAGE REGULATOR [M]
IC2103 C0ABBB000230 IC OP-AMP [M]
IC2801 RFKWVK470GC IC MICRO-PROCESSOR [M]
IC2803 C1BB00001121 IC ASP [M]
IC2804 C0AABB000125 IC OP-AMP [M]
IC2900 C9ZB00000461 IC DSP [M]
IC4000 C0DAAMH00012 IC SWITCHING REGULATOR [M]
IC4001 C0DAAYY00042 IC SWITCHING REGULATOR [M]
IC5000 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5500 C0JBAB000902 IC INVERTER GATE [M]
IC5501 C0JBAF000716 IC D-TYPE FLIP-FLOP [M]
IC5701 C5HACYY00003 IC SWITCHING REGULATOR [M]
IC5799 MIP4110MSSCF IC SWITCHING REGULATOR [M]
IC5801 C0DABFC00002 IC SHUNT REGULATOR [M]
IC5899 C0DAEMZ00001 IC SHUNT REGULATOR [M]
IC6000 C0ABBB000230 IC IPOD DIFFERENTIAL AMP [M]
IC6601 C0HBB0000057 IC FL DRIVER [M]
IC8001 MN2DS0018MP IC DV5.0 LSI [M]
IC8051 C3ABPY000011 IC 64M SDRAM [M]
IC8111 C0CBCBD00018 IC +3.3V DC-DC CONVERTER [M]
IC8151 C0DBEHG00006 IC +1.2V REGULATOR [M]
IC8251 C0GBG0000048 IC MOTOR DRIVE [M]
IC8420 C0FBBK000047 IC AUDIO DAC [M]
IC8601 C0EBA0000039 IC RESET [M]
IC8606 C0EBE0000456 IC RESET [M]
IC8611 C3EBGC000056 IC EEPROM [M]
IC8651 RFKWMH32B325 IC FLASH ROM [SPG]
IC8691 C0JBAA000502 IC AND GATE [M]
IC8695 C0JBAA000502 IC AND GATE [M]
IC9001 C0JBAZ001251 IC LATCH [M]
IC9002 C0JBAZ001251 IC LATCH [M]
IC9003 C0JBAB000908 IC INVERTER GATE [M]
IC9005 C0DBZYY00266 IC REGULATOR [M]
TRANSISTORS
Q1101 B1ABGC000001 TRANSISTOR [M]
Q1201 B1ABGC000001 TRANSISTOR [M]
Q1302 B1GDCFJJ0002 TRANSISTOR [M]
Q1303 B1GBCFGH0001 TRANSISTOR [M]
Q1304 B1GDCFGH0002 TRANSISTOR [M]
Q1306 B1ABCF000011 TRANSISTOR [M]
Q1307 B1ABCF000011 TRANSISTOR [M]
Q1309 B1AAGC000006 TRANSISTOR [M]
Q1310 B1AAGC000006 TRANSISTOR [M]
Q1312 B1ABCF000011 TRANSISTOR [M]
Q1314 B1GDCFGH0002 TRANSISTOR [M]
Q1315 B1ACKD000006 TRANSISTOR [M]
Q1316 2SD09650RA TRANSISTOR [M]
Q1317 B1ABGC000001 TRANSISTOR [M]
Q2004 2SD0601AHL TRANSISTOR [M]
Q2005 B1ADCE000012 TRANSISTOR [M]
Q2011 B1GBCFJJ0051 TRANSISTOR [M]
Q2012 B1GBCFJJ0051 TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q2051 B1GDCFJJ0047 TRANSISTOR [M]
Q2052 B1GFGCAA0001 TRANSISTOR [M]
Q2142 B1ABCF000176 TRANSISTOR [M]
Q2143 B1ABEB000002 TRANSISTOR [M]
Q2242 B1ABCF000176 TRANSISTOR [M]
Q2243 B1ABEB000002 TRANSISTOR [M]
Q2366 B1GFGCAA0001 TRANSISTOR [M]
Q2501 B1GDCFJJ0047 TRANSISTOR [M]
Q2502 B1GFGCAA0001 TRANSISTOR [M]
Q2600 B1GBCFLL0037 TRANSISTOR [M]
Q2700 B1ACCF000094 TRANSISTOR [M]
Q2701 B1GBCFJN0033 TRANSISTOR [M]
Q2702 B1ACCF000094 TRANSISTOR [M]
Q2800 B1GBCFJJ0051 TRANSISTOR [M]
Q2810 B1AAKD000012 TRANSISTOR [M]
Q2900 B1BABK000001 TRANSISTOR [M]
Q2912 B1GBCFJN0033 TRANSISTOR [M]
Q2980 B1ABCF000176 TRANSISTOR [M]
Q4000 B1BACD000018 TRANSISTOR [M]
Q4001 B1GBCFJN0033 TRANSISTOR [M]
Q4002 B1BCCG000002 TRANSISTOR [M]
Q4003 2SD0592ARA TRANSISTOR [M]
Q4005 B1ABCF000176 TRANSISTOR [M]
Q4006 B1ADCF000001 TRANSISTOR [M]
Q4007 2SD0592ARA TRANSISTOR [M]
Q5100 B1BACG000023 TRANSISTOR [M]
Q5101 B1ABCF000176 TRANSISTOR [M]
Q5102 B1ABCF000176 TRANSISTOR [M]
Q5601 B1ABCF000176 TRANSISTOR [M]
Q5603 B1ADCE000012 TRANSISTOR [M]
Q5604 B1ABCF000176 TRANSISTOR [M]
Q5720 2SC3940ARA TRANSISTOR [M]
Q5721 2SA207700L TRANSISTOR [M]
Q5722 B1ABCF000176 TRANSISTOR [M]
Q5802 B1ABCF000176 TRANSISTOR [M]
Q5803 2SC3940ARA TRANSISTOR [M]
Q5860 2SA207700L TRANSISTOR [M]
Q5861 B1ABCF000176 TRANSISTOR [M]
Q5862 B1ABCF000176 TRANSISTOR [M]
Q5898 B1ABCF000176 TRANSISTOR [M]
Q6511 B1GBCFJN0033 TRANSISTOR [M]
Q6600 B1GBCFJN0033 TRANSISTOR [M]
Q6601 B1GBCFJN0033 TRANSISTOR [M]
Q6602 B1GBCFJN0033 TRANSISTOR [M]
Q6603 B1GBCFJN0033 TRANSISTOR [M]
Q6910 B1GBCFJJ0051 TRANSISTOR [M]
Q8321 2SB1218ARL TRANSISTOR [M]
Q8325 2SB1218ARL TRANSISTOR [M]
Q8331 2SB1218ARL TRANSISTOR [M]
Q8335 2SB1218ARL TRANSISTOR [M]
Q8341 2SB1218ARL TRANSISTOR [M]
Q8551 2SD1819A0L TRANSISTOR [M]
Q8552 B1ADGB000008 TRANSISTOR [M]
Q8561 2SD1819A0L TRANSISTOR [M]
Q8562 B1ADGB000008 TRANSISTOR [M]
Q8563 B1CFHA000002 TRANSISTOR [M]
Q8564 B1CFHA000002 TRANSISTOR [M]
Q8565 2SD1819A0L TRANSISTOR [M]
QR4004 B1GBCFJN0033 TRANSISTOR [M]
QR5801 UNR221400L TRANSISTOR [M]
QR5802 B1GDCFGA0018 TRANSISTOR [M]
QR5810 B1GBCFLL0037 TRANSISTOR [M]
QR8111 XP0621400L TRANSISTOR [M]
QR8420 UNR521100L TRANSISTOR [M]
QR9030 B1GDCFJJ0002 TRANSISTOR [M]
DIODES
D971 MA2C16500E DIODE [M]
D1301 B0ACCK000005 DIODE [M]
D2000 B0EAKM000117 DIODE [M]
D2001 B0EAKM000117 DIODE [M]
D2002 B0EAKM000117 DIODE [M]
