Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F401.40
2
K5D802BNA005 TIME LAG FUSE HIGH 2
C11 K1MN55BA0076 55P CONNECTOR 1
C12 K1KA04BA0107 4P CONNECTOR 1
C21 K1MN55BA0076 55P CONNECTOR 1
C22 K1KA04BA0107 4P CONNECTOR 1
C24 K1KA04AA0150 4P CONNECTOR 1
C31 K1MN55BA0076 55P CONNECTOR 1
C32 K1KA12AA0153 12P CONNECTOR 1
C33 K1KA04BA0107 4P CONNECTOR 1
C41 K1MN55BA0076 55P CONNECTOR 1
C43 K1KA04BA0107 4P CONNECTOR 1
C402 ECJ2XC1H101J C 100PF, J, 50V 1
C403 ECKCNA222MEB C 2200PF, M 1
C404 F0CAF105A021 C 1UF, 250V 1
C405 ECJ2XB1H103K C 0.01UF, K, 50V 1
C407 ECA2WHG220 E 22UF, 450V 1
C409 F0CAF105A021 C 1UF, 250V 1
C410 ECJ3YB1E105K C 1UF, K, 25V 1
C411-14 ECJ2XB1H103K C 0.01UF, K, 50V 4
C415,16 F1A3A102A040 C 1000PF, J, 1KV 2
C417 ECJ2XB1H103K C 0.01UF, K, 50V 1
C418 F1J1C1050011 C 1UF, Z, 50V 1
C419 F1A3A102A040 C 1000PF, J, 1KV 1
C421,22 ECJ2XB1H103K C 0.01UF, K, 50V 2
C423 ECJ2XB1H472K C 4700PF, K, 50V 1
C424 F1A3A102A040 C 1000PF, J, 1KV 1
C425 ECJ2XB1H103K C 0.01UF, K, 50V 1
C426 ECJ2XC1H471J C 470PF, J, 50V 1
C427 F1J1C1050011 C 1UF, Z, 50V 1
C428 ECJ2XC1H221J C 220PF, J, 50V 1
C429,30 F1K2J1530002 C 0.15PF, J,630V 2
C431 ECJ2XB1H102K C 1000PF, K, 50V 1
C432-34 F1J1C1050011 C 1UF, Z, 50V 3
C436 F1J1C1050011 C 1UF, Z, 50V 1
C440 ECA1HM100 E 10UF, 50V 1
C443,44 F1A3A102A040 C 1000PF, J, 1KV 2
C445 F1J1C1050011 C 1UF, Z, 50V 1
C446 F2B2W3910005 C 390UF, 450V 1
C451 F1A3A101A040 C 100PF, J, 1KV 1
C457 ECWH12333RHV P 0.013UF,J,1.2KV 1
C459 F1K2J1530002 C 0.15PF, J,630V 1
C460,61 F1A3A331A039 E 330UF, 1KV 2
C462 ECJ3YB1E105K C 1UF, K, 25V 1
C463 ECJ2XC1H220J C 22UF, J, 50V 1
C465 ECKCNA221KB7 C 220PF, M, 1
C467 ECKCNA221KB7 C 220PF, M, 1
C468 ECJ2XB1H103K C 0.01UF, K, 50V 1
C470 F0CAF105A021 C 1UF, 250V 1
C471 F1J1C1050011 C 1UF, Z, 50V 1
C473 ECKCNA221KB7 C 220PF, M, 1
C476 ECKCNA221KB7 C 220PF, M, 1
C482 ECJ2XB1H104K C 0.1UF, K, 50V 1
C490 ECJ2XC1H331J C 330PF, J, 50V 1
C491 ECJ2XB1E104K C 0.1UF, K, 25V 1
C492 ECJ2XC1H271J C 270PF, J, 50V 1
C493 ECA1EM101 E 100UF, 25V 1
C494,95 ECJ2XC1H101J C 100PF, J, 50V 2
C496 F1J1C1050011 C 1UF, Z, 50V 1
C497 ECA1EM221 E 220UF, 25V 1
C498 ECJ2XB1H104K C 0.1UF, K, 50V 1
C501-03 ECJ2XB1H103K C 0.01UF, K, 50V 3
C504 F1J1C1050011 C 1UF, Z, 50V 1
C505 ECJ2XB1H102K C 1000PF, K, 50V 1
C506-08 ECJ2XB1H103K C 0.01UF, K, 50V 3
C509 ECA1EM101 E 100UF, 25V 1
C510 ECJ2XB1H104K C 0.1UF, K, 50V 1
C511 ECA1EM331 E 330UF, 25V 1
C512-14 ECJ2XC1H471J C 470PF, J, 50V 3
C515 ECA1CM222 E 2200UF, 16V 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C516 ECJ2XB1C474K C 0.47UF, Z, 16V 1
C517 F2D1E1010001 E 10UF, 25V 1
C518,19 F1J1C1050011 C 1UF, Z, 50V 2
C523 ECJ3YB1E105K C 1UF, K, 25V 1
C525 F2A1E8210012 E 820UF, 25V 1
C526 ECJ2XB1H104K C 0.1UF, K, 50V 1
C527 ECJ3YB1E475K C 4.7UF, K, 25V 1
C528,29 F1J1C1050011 C 1UF, Z, 50V 2
C530 ECJ2VB1H333K C 0.033UF, K, 50V 1
C533 ECJ2XB1H103K C 0.01UF, K, 50V 1
C534 ECJ2XC1H471J C 470PF, J, 50V 1
C546,47 ECJ2VB1H333K C 0.033UF, K, 50V 2
C548 ECJ2XB1H104K C 0.1UF, K, 50V 1
C551-53 ECJ2XB1H104K C 0.1UF, K, 50V 3
C554 F1J1C1050011 C 1UF, Z, 50V 1
C555 ECA2AM101 E 100UF, 100V 1
C556 F2A1C1520009 E 1500UF, 16V 1
C557 F2A1E1520089 E 1500UF, 25V 1
C562 ECJ2XB1H104K C 0.1UF, K, 50V 1
C572 ECJ2XB1H104K C 0.1UF, K, 50V 1
C574 ECJ2XB1H104K C 0.1UF, K, 50V 1
C577 ECA2AM330 E 33UF, 100V 1
C581 ECJ2XB1H223K C 0.022UF, K, 50V 1
C583 ECJ2XB1H102K C 1000PF, K, 50V 1
C584 ECJ2XB1H223K C 0.022UF, K, 50V 1
C587 ECJ2XB1H103K C 0.01UF, K, 50V 1
C591,92 F1K2J1530002 C 0.15PF, J,630V 2
C601 ECJ2XB1H103K C 0.01UF, K, 50V 1
C603 ECA1HM470 E 47UF, 50V 1
C604,05 F2A2C1510004 E 150UF, 160V 2
C606,07 F1J1C1050011 C 1UF, Z, 50V 2
C608,09 ECJ2XB1H103K C 0.01UF, K, 50V 2
C610 F1J1C1050011 C 1UF, Z, 50V 1
C611 F2B2T1420001 E 142UF, 220V 1
C612 ECJ2XB1H103K C 0.01UF, K, 50V 1
C615 F2B2T1420001 E 142UF, 220V 1
C616 F1A3A102A040 C 1000PF, J, 1KV 1
C619 ECJ2XB1H104K C 0.1UF, K, 50V 1
C620 ECJ2XB1H103K C 0.01UF, K, 50V 1
C623 ECA1HM100 E 10UF, 50V 1
C624 ECJ3YB1E105K C 1UF, K, 25V 1
C626 ECJ2XB1H103K C 0.01UF, K, 50V 1
C629 ECJ2XB1H103K C 0.01UF, K, 50V 1
C631 ECJ2XB1H103K C 0.01UF, K, 50V 1
C633 ECJ2XB1H103K C 0.01UF, K, 50V 1
C634 ECJ2XB1H102K C 1000PF, K, 50V 1
C635 ECJ2XB1H103K C 0.01UF, K, 50V 1
C636 F1J1C1050011 C 1UF, Z, 50V 1
C637 ECJ2XB1H104K C 0.1UF, K, 50V 1
C638,39 ECJ2XB1H103K C 0.01UF, K, 50V 2
C640 ECJ2XB1H104K C 0.1UF, K, 50V 1
C641 ECJ2XB1H102K C 1000PF, K, 50V 1
C643 ECA1HM470 E 47UF, 50V 1
C801,02 EEVHB1C471 E 470UF, 16V 2
C804 ECJ2XB1H222K C 2200PF, K, 50V 1
C805 ECJ1VB1C105K C 0.01UF, K, 16V 1
C806 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C807 ECJ3XF1C475Z C 4.7UF, Z, 16V 1
C808 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C809 TCUY1C225KBM C 2.2UF, 16V 1
C811,12 EEVHB1C471 E 470UF, 16V 2
C814 ECJ2XB1H472K C 4700PF, K, 50V 1
C815 ECJ1VB1C105K C 0.01UF, K, 16V 1
C816 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C817 ECJ3XF1C475Z C 4.7UF, Z, 16V 1
C818 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C819 TCUY1C225KBM C 2.2UF, 16V 1
C820 ECJ2XC1H820J C 82PF, J, 50V 1
C821 F2H0J102A010 C 1000UF, 6.3V 1
C822 EEVHB1C471 E 470UF, 16V 1
C824 ECJ2XB1H472K C 4700PF, K, 50V 1
19.2. Electrical Replacement Parts List (37 inch)
