Panasonic TH-37PHD8GK - 5 PCB Structure Sheet of GPH8 D Chassis

5 PCB Structure sheet of GPH8D chassis
Board Name Function Remarks
D Digital Signal Processor, Format Converter,
Plasma AI Processor
1
J Slot Interface (Audio/Video/Sync input Switch),
SYNC processor, Audio processor,
Speaker out amplifier, DC-DC converter
1
SS Sustain drive 1
SC Scan drive 1
SU Scan out (Upper) 1
SD Scan out (Lower) 1
C1 Data Drive (Upper Right)
C2 Data Drive (Upper Left)
C3 Data Drive (Lower Left)
C4 Data Drive (Lower Right)
H3 Speaker terminal
S1 Power switch
SS2 Sustain out (Upper) 2
SS3 Sustain out (Lower) 2
V1 LED (stand-by / Power on) & Remote receiver 1
V2 Key switch 1
PB Fan control 1
P Line filter, Power supply 1
HX PC / RS-232C_Input terminal
HB BNC Composite Video 3
HA BNC Component Video 3
Remarks
1: Recommend PCB´s for initial service for GPH8D chassis.
2: For TH-42PHD8GK/GS/UK
3: For TH-37/42PHD8UK
9
TH-37PHD8GK / TH-37PHD8GS / TH-37PHD8UK / TH-42PHD8GK / TH-42PHD8GS / TH-42PHD8UK
