Panasonic TH-37PHD8GK - Default Chapter; Table of Contents

1 Applicable signals 5
2 Safety Precautions
6
2.1. General Guidelines
6
3 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
7
4 About lead free solder (PbF)
8
5 PCB Structure sheet of GPH8D chassis
9
6 Service Hint
10
7 Disassembly TH-37PHD8
12
7.1. Removal of the Back Cover
12
7.2. Removal of the HA-Board and the HB-Board
12
7.3. Removal of the Slot Block
12
7.4. Removal of the J-Board
13
7.5. Removal of the HX-Board
13
7.6. Removal of the PB-Board
13
7.7. Removal of the D-Board
14
7.8. Removal of the P-Board
14
7.9. Removal of the H3-Board(L, R)
15
7.10. Removal of the SU-Board and the SD-Board
15
7.11. Removal of the SC-Board
16
7.12. Removal of the SS-Board
16
7.13. Removal of the C1, C2, C3 and the C4-Board
16
7.14. Removal of the S1-Board
17
7.15. Removal of the Fan
18
7.16. Removal of the Escutcheon
18
7.17. Removal of the V1-Board and the V2-Board
19
Connection terminals
A
V (UK) VIDEO IN / OUT (BNC) 1.0 Vp-p (75-ohm or high impedance)
S VIDEO IN (MINI DIN 4PIN) Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)
A
UDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
COMPONENT / RGB (UK)
Y
/ G (BNC) 1.0 Vp-p
/
composite (75-ohm)
0.7 Vp-p
/
non-composite (75-ohm)
P
B
/B (BNC), P
R
/R (BNC) 0.7 Vp-p (75-ohm)
A
UDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
PC (HIGH-DENSIT
Y
Mini-D-SUB 15PIN) R,G,B
/
0.7 Vp-p (75-ohm)
Component
Y
:1.0 Vp-p (75-ohm : include sync)
P
B
/
C
B
:0.7 Vp-p (75-ohm)
P
R
/
C
R
:0.7 Vp-p (75-ohm)
HD, VD
/
1.0 - 5.0 Vp-p (high impedance)
A
UDIO IN (M3 JACK) 0.5 Vrms (high impedance)
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
SPEAKERS (6Ω) 16 W [8 W + 8 W] (10 % THD)
Accessories Supplied
Remote Control Transmitter EUR7636070R
Batteries 2×
AA
Size
Fixing bands (TMME203 or TMME187) × 2
Dimensions (
W
×H×D) 36.2” (920 mm) × 21.7” (550 mm) × 3.5” (89 mm) 40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)
(exclusive of protruding portion) (37 inch) (exclusive of protruding portion) (42 inch)
Mass (weight) (UK)
main unit onl
y
approx. 57.3 lbs (37 inch) approx. 69.4 lbs (42 inch)
with speakers approx. 66.1 lbs (37 inch) approx. 78.3 lbs (42 inch)
Mass (weight) (GK/GS)
main unit onl
y
approx. 56.2 lbs (37 inch) approx. 68.3 lbs (42 inch)
with speakers approx. 65.0 lbs (37 inch) approx. 77.2 lbs (42 inch)
Notes:
· Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
CONTENTS
Page Page
2
TH-37PHD8GK / TH-37PHD8GS / TH-37PHD8UK / TH-42PHD8GK / TH-42PHD8GS / TH-42PHD8UK
