Panasonic TH-65PF9UK - 16 Mechanical Replacement Parts List

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 EUR7636070R REMOTE CONTROLER 1
J0KD00000096 FERRITE CORE 6
J0KD00000096 FERRITE CORE 3
J0KG00000011 FERRITE CORE 1
J0KG00000052 FERRITE CORE 1
J0KG00000052 FERRITE CORE 1
2 K2AHYH000009 AC INLET 1
3 K2CG3DH00025 AC CORD 1
4 L6FALEFH0041 FAN (80MM) 2
5 L6FAYYYH0025 FAN 4
6 L6FAYYYH0026 FAN 1
7 MD65F09A1J PLASMA DISPLAY
PANEL
1
8 TBMA208 PANASONIC BADGE 1
9 TBXA38902 HINDGE BUTTON 1
10 TBXA44801A POWER BOTTON 1
11 TESD031 SPRING 1
12 TKGA5311S FRONT GLASS 1 PAVCA
13 TKKC5105 LED PANEL 1
14 TKKL5266 COVER 1
15 TKPA60301 REMOCON RECEIVE
PANEL
1
16 TKRA45301 HANDLE 2
17 TMKG469-1 SPONGE (FAN) 6
TMKG539 SPONGE 2
18 TMKG572 CUSHION (TOP /
BOTTOM)
2
19 TMKG573 CUSHION
(RIGHT/LEFT)
2
TMKG630 SPONGE(20X25XT25) 2
20 TMKG656 FAN SPONGE 2
TMM17499 CLAMPER 1
TMM25401 CLAMPER 3
TMM6463-1 CLAMPER 1
TMM6463-1 CLAMPER 2
TMM7464-2 CLAMPER 1
TMM7468-1 CLAMPER 1
TMME002 CLAMPER 1
TMME047 CLAMPER 1
TMME061 CLAMPER 3
TMME075 EADG SADOLE 4
TMME088 CLAMPER 3
TMME152 CLAMPER 2
TMME152 CLAMPER 3
TMME185 CLAMPER 2
21 TMME187 CLAMPER 2
TMME189 CLAMPER 1
TMME189 CLAMPER 1
TMME190 CLAMPER 3
TMME199 CLAMPER 1
TMME199 CLAMPER 2
TMME226 AC CORD CLAMPER 2
TMME228 CLAMPER 2
22 TMMJ068 RUBBER(FAN) 16
TMMX095 BRACKET 2
23 TMWC016 P BUTTON BRAKET 1
TPD169487 JOINT 4
TPDA1038 CUSHION (CENTER) 2
TPDA1153 CUSHION (CORNER) 2
TPDA1154 CUSHION
(CENTER/TOP)
1
TPDF0737 PAPER BOX 1
TPDX0007 JOINT 4
TPEH246 PROTECT COVER 1
TQB2AA0691 FAN BAG COVER 1 PAVCA
24 TQB2AA0721 INSTRUCTION
BOOK(ENGLISH)
1 PAVCA
25 TSXL519 CABLE(C11-C22/C52-
C61)
2
26 TSXL555 CABLE(C21-C31/C41-
C51)
2
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
27 TSXL564 CABLE(D31-C10/D32-
C24/D33
3
28 TSXL566 CABLE(D34-C55/D35-
C54/D36
3
29 TSXL584 CABLE(DN6-DS5) 1
30 TSXL585 CABLE(DN1-DS1) 1
31 TXFKU23QSER REAR COVER 1 PAVCA
32 TXFKE01YPTJ ESCUTCHEON ASSY 1
TXJSPLYPTJ SPEAKER LEAD(LEFT) 1
TXJSPRYPTJ SPEAKER
LEAD(RIGHT)
1
THEA068N SCREW 6
THEA130N SCREW (SPACER) 4
THEL0239 SCREW 12
THEL027N SCREW 12
THEL0429 SCREW 15
THTD011J SCREW 3
THTD013N SCREW 16
THTF011N SCREW 100
XTB4+8JFJ SCREW 4*8MM 52
XTS3+10JFJ SCREW 1
XTV3+10JFJ SCREW 2
XTW3+8TFJ SCREW 6
XYN3+F8FJ SCREW 19
XYN3+J12FJ SCREW 101
XYN4+E8FJ SCREW 1
XYN4+F10FJ SCREW 87
XYN4+F10FJK SCREW 9
XYN4+F20FJ SCREW 16
XYN4+F32FJ SCREW 4
XYN4+F38FJK SCREW 12
XYN5+F12FJ SCREW 16
XYN8+F20FJK SCREW 20
XYN8+F30FJK SCREW 4
16 Mechanical Replacement Parts List
153
TH-65PF9UK
